「2020最新」Spring最易学习教程—IOC 以及 整合Struts2
0 复习 工厂设计模式 使用工厂代替new模式创建对象,目的:解耦合 Spring工厂的使用 applicationContext.xml中配置 bean标签 编码:创建工厂,从工厂中获取对象 Spring中属性注入 简单类型(基本类型+包装类+String) <beanid="标识名"class="全类名"><propertyname="属性"><value>值</value></property><propertyname="属性"value="值"/></bean> 对象类型 <beanid="a"class="Address的全类名"><propertyname="属性1"value="值1"/><propertyname="属性2"value="值2"/></bean><beanid="p"class="Person全类名"><propertyname="addr"><refbean="a"/></property></bean><beanid="p2"class="Person全类名"><propertyname="addr"ref="a"/></bean> 数组+List+Set Map+Properties 1 注入补充 1.1 null值 当需要显式的为属性赋值为 null 时,通过 null标签完成。 <beanid="u"class="com.bcl.entity.User"><constructor-argvalue="1"index="0"/><constructor-argvalue="xiaohei"index="1"/><constructor-argindex="2"><null/></constructor-arg></bean> 1.2 内部bean <beanid="a"class="com.bcl.entity.Address"><propertyname="street"value="文化路"/><propertyname="city"value="硅谷"/></bean><beanid="p"class="com.bcl.entity.Person"><propertyname="personId"value="1"/><propertyname="personName"value="xiaohei"/><propertyname="addr"ref="a"/></bean>可以使用内部bean替换的写法<beanid="p"class="com.bcl.entity.Person"><propertyname="personId"value="1"/><propertyname="personName"value="xiaohei"/><propertyname="addr"><beanclass="com.bcl.entity.Address"><propertyname="city"value="郑州"/><propertyname="street"value="文化路"/></bean></property></bean> 2 FactoryBean技术(创建复杂对象) 2.1 FactoryBean引言 Spring工厂要管理程序中各种种类的对象。 image-20200601102514322 2.2 FactoryBean的开发步骤 编码 实现FactoryBean接口 publicclassConnectionFactoryBeanimplementsFactoryBean<Connection>{@Override//返回复杂对象publicConnectiongetObject()throwsException{//1加载驱动Class.forName("com.mysql.jdbc.Driver");//2建立连接Stringurl="jdbc:mysql://localhost:3306/bcl2002?useUnicode=true&characterEncoding=utf8";Stringusername="root";Stringpassword="root";Connectionconn=DriverManager.getConnection(url,username,password);returnconn;}@Override//返回复杂对象的类型publicClass<?>getObjectType(){returnConnection.class;}@Override//复杂对象是否单例 true:单例 false:多例publicbooleanisSingleton(){returntrue;}} 配置 <!--配置factoryBean的全类名,根据id:conn获取到是Connection对象--><beanid="conn"class="com.bcl.factory.ConnectionFactoryBean"/> 注意: 根据id获取到的复杂对象,不是FactoryBean 可以根据&id获取到FactoryBean 复杂对象的单例与否,只与isSingleton方法有关 3 Spring中对象的生命周期(了解) 生命周期: 从生到死的过程。 多例时 (scope="prototype") 对象在getBean时创建 单例时(scope="singleton") 对象在工厂创建时随之创建初始化:init-method:对象创建后,执行1次方法销毁:destroy-method:对象销毁时,执行1次的方法对象在工厂关闭时销毁 4 Spring配置文件分析 4.1 Spring配置文件的拆分 应用复杂时,需要将配置文件拆分成多个小的配置文件,放置到不同模块,最后在总配置文件中通过import标签引入其它的小配置文件。 <importresource="classpath:a/applicationContext-a.xml"/><importresource="classpath:b/applicationContext-b.xml"/> 4.2 Spring 中xsd文件 xsd(XML Schema Definition)文件,规定了一个xml可以使用哪些标签、哪些属性,以及它们的顺序。 xsd的基本使用 image-20200601113429666 使用xsd文件,要配置xsd的命名空间,以及文件路径对。 在一个xml中使用多个xsd image-20200601114026438 示例: image-20200601120115361 4.3 Spring配置文件中拆分jdbc.properties 抽取jdbc.properties jdbc.driverClassName=com.mysql.jdbc.Driverjdbc.url=jdbc:mysql://localhost:3306/bcl2002?useUnicode=true&characterEncoding=utf8jdbc.username=rootjdbc.password=root 读取配置文件 <context:property-placeholderlocation="classpath:jdbc.properties"/> 使用jdbc.properties中的参数 <beanid="conn"class="com.bcl.factory.ConnectionFactoryBean"><propertyname="driverClassName"value="${jdbc.driverClassName}"/><propertyname="url"value="${jdbc.url}"/><propertyname="username"value="${jdbc.username}"/><propertyname="password"value="${jdbc.password}"/></bean> 注意:${username} 会优先读取操作系统用户名,可以给参数添加前缀进行区分。 5 Spring IOC和DI IOC(Inversion Of Control)控制反转 (思想) DI(Dependency Injection)依赖注入 (实现手段) 控制:对于对象属性赋值的控制权力。 image-20200601141742924 正向控制的问题:强耦合。 解决方案:控制反转。 image-20200601142542072 结论:要解耦合,就不要new,转为在spring配置文件中通过配置的方式由工厂创建对象。 6 Spring整合Struts2 准备工作:创建好一个可运行的struts2项目。 6.1 整合效果 image-20200601152503882 Spring整合Struts2的效果:由Spring工厂创建Struts2需要的Action和Service. 6.2 实战 导入spring-web 依赖 <dependency><groupId>org.springframework</groupId><artifactId>spring-web</artifactId><version>4.3.26.RELEASE</version></dependency><dependency><groupId>org.apache.struts</groupId><artifactId>struts2-spring-plugin</artifactId><version>2.3.16.3</version></dependency> tomcat启动应用时,自动创建Spring工厂 web.xml <context-param><param-name>contextConfigLocation</param-name><param-value>classpath:applicationContext.xml</param-value></context-param><listener><listener-class>org.springframework.web.context.ContextLoaderListener</listener-class></listener> Struts2从Spring工厂中获取Action applicationContext.xml <beanid="userService"class="com.bcl.service.impl.UserServiceImpl"/><beanid="userAction"class="com.bcl.action.UserAction"scope="prototype"><propertyname="userService"ref="userService"/></bean> struts.xml <packagename="day02"extends="struts-default"namespace="/day02"><!--class配置的是spring配置文件中Action的id--><actionname="showAllUsers"class="userAction"method="showAllUsers"><resultname="success">/showAllUsers.jsp</result></action></package> 7 Spring整合JUnit 之前的JUnit测试Spring框架,每次都需要读取配置文件,创建工厂,测试繁琐。 解决方案:使用 spring-test 进行测试 准备工作: <dependency><groupId>junit</groupId><artifactId>junit</artifactId><version>4.12</version><scope>test</scope></dependency><dependency><groupId>org.springframework</groupId><artifactId>spring-test</artifactId><version>4.3.26.RELEASE</version></dependency> 简化测试: @RunWith(SpringJUnit4ClassRunner.class)@ContextConfiguration("classpath:applicationContext.xml")publicclassApplicationContextTest{@AutowiredprivateUseru;@TestpublicvoidtestUser(){System.out.println("u="+u);}} 8 Spring基于注解的配置方式 使用注解替换xml配置的好处:简化配置、提高开发效率。 注解的不足:不利于配置的管理。 8.1 使用注解的思路 image-20200601165433399 操作思路: 使用Component注解替换bean标签配置 使用Autowired注解替换property标签 8.2 注解开发的步骤 给类和属性添加注解 @Component("userService")publicclassUserServiceImplimplementsUserService{...}@Component("userAction")publicclassUserAction{@AutowiredprivateUserServiceuserService;publicvoidsetUserService(UserServiceuserService){this.userService=userService;}...} 查找注解:配置查找注解的起始包名 applicationContext.xml<!--<context:component-scanbase-package="com.bcl.action,com.bcl.service.impl"/>--><context:component-scanbase-package="com.bcl"/> 8.3 核心注解 @Component Component注解替换bean标签,创建对象。与其作用相同还有3个注解: @Controller 用在action层 @Service 用在service层 @Repository 用在dao层 注意事项: 后3个注解实际开发时使用频率更高,比Component有更高的辨识度 MyBatis框架中,Repository没有使用场景 4个注解在使用时,都可以省略id参数。会有默认id:类名首字母小写 UserAction==> userAction UserServiceImpl ==> userServiceImpl @Autowired 用于属性注入。 注意事项: 默认根据类型查找所需要的属性对象 Autowired 用于属性上,底层通过反射操作属性赋值 Autowired用在set方法上,底层通过调用set方法赋值 @Qualifier 当Autowired注入属性,Spring中有不止一个满足条件的对象,为了分辨使用哪个对象,可以通过@Qualifier("bean的id") 确定。 @Controller("userAction")publicclassUserAction{@Autowired@Qualifier("userServiceImpl2")privateUserServiceuserService;...} @Scope 决定是否单例。 @Controller("userAction")@Scope("prototype")publicclassUserAction{...} 业内标准: 对于自定义的类型,使用注解。比如:dao、service、action 第3方类型,使用xml。比如:数据库连接池、事务管理器 「❤️ 帅气的你又来看了我」 如果你觉得这篇内容对你挺有有帮助的话: 点赞支持下吧,让更多的人也能看到这篇内容(收藏不点赞,都是耍流氓 -_-) 欢迎在留言区与我分享你的想法,也欢迎你在留言区记录你的思考过程。 觉得不错的话,也可以关注 编程鹿 的个人公众号看更多文章和讲解视频(感谢大家的鼓励与支持🌹🌹🌹) 本文分享自微信公众号 - 鹿小洋的Java笔记(lulaoshiJava)。如有侵权,请联系 support@oschina.cn 删除。本文参与“OSC源创计划”,欢迎正在阅读的你也加入,一起分享。
