关于项目自动化测试架构的改良计划 - DataProviderEngine架构
为了基于上文我们的xml文件的架构，对其进行解析，我自己写了一个DataProviderEngine作为解析xml文件的引擎，它主要的架构如下图： 具体细节如下，为了节省时间，我直接复制我的英文邮件内容了： Step 1: The XMLReader read the raw test suite xml file (now we adopt the xml file ,since it is not binary file and easy to edit and version control) Step 2: After reading ,XMLReader store the xml string into a string variable named “ originalXmlString “, this is our starting point. Step 3: The XIncludeConverter read the originalXmlString ,and resolve the XInclude namespace ,when it resolve this file ,it will replace all the <xi:include href> element with the actual xml fragments one by one. Step 4: After replacing all <xi:include> ,XIncludeConverter will store the new xml string into string variable named “convertedXmlString”. Step 5: The XMLManipulator read the convertedXmlString ,and remove all the user configuration part from such as <add_elements>,<update_elements>,<remove_elements> ,since these information is used for letting test case end user configure how to operate the base data to meet special requirements,so these part shouldn’t exist in final data. Step 6:After removing all config elements ,The XMLManipulator store the xml string into a new string variable named “ removeAllConfXmlString” Step 7:Since the configuration information are removed in Step 5-6 ,but they still exist in original xml string ,so XMLModifyInfoExtractor read all the <add_elements>,<update_elements>,<remove_elements> part from original xml string ,and smartly match which corresponding testcase data it will operate . Step 8:After analyzing all the user modification requirement ,the XMLModifyInfoExtractor store these modification info into 3 arraylists , addElementInfoList,updateElementInfoList,removeElementInfoList. Step 9:Now it is time to begin modifying the xml ,so the XMLManipulator read the “removeAllConfXmlString” in Step 6 . Step 10:Then XMLManipulator use all the modification info in Step 8 ,and do modification operation one by one : addElementToXML() ,updateElementFromXML(),removeElementFromXML() Step 11: after finish all the modification ,XMLManipulator store the final xml string into string variable named “modifiedXmlString” Step 12: Finally it convert the xml formatted string to a jsonobject and it now can be used as a data provider which can be consumed in each test case. 本文转自 charles_wang888 51CTO博客，原文链接：http://blog.51cto.com/supercharles888/1221708，如需转载请自行联系原作者
