撰文 | 赵露阳

• 新增动态图特性：OneFlow 默认以动态图模式（eager）运行，与静态图模式（graph）相比，更容易搭建网络、调试和验证算法。

• 面向对象式的动态图接口 nn.Module，熟悉 PyTorch 的用户可以轻松上手。

• “一行代码转换 OneFlow 与 PyTorch 网络”：与 PyTorch 对齐的算子数目增加至200+。在 ResNet50、AlexNet 等 十几个常用网络 上已通过 import oneflow as torch 和 import torch as flow 验证。注意：此特性是为方便用户由 PyTorch 迁移至 OneFlow 而设计，并不是承诺完全兼容 PyTorch。

• 面向对象式的静态图接口：新增面向对象的静态图接口 nn.Graph。保留了 OneFlow 静态图性能优势的同时，让静态图的编程门槛与动态图接近，期待更多的算法工程师把 OneFlow 的高性能优势玩起来。这是一个用 nn.Graph 搭建 ResNet50 示例

• 易用高效的分布式训练：分布式训练是大势所趋，OneFlow 本版本新增的 Consistent Tensor，让用户可以像操作单机单卡一样，操作整个集群，并立即看到效果。新增的 launch 模块、DDP 模块 配合 OneFlow 的一致性视角 让用户轻松启动分布式训练，无论是 数据并行、模型并行、还是流水并行，OneFlow 均原生支持，易用高效。

https://github.com/Oneflow-Inc/oneflow/pull/5406https://github.com/Oneflow-Inc/oneflow/pull/5500https://github.com/Oneflow-Inc/oneflow/pull/5644https://github.com/Oneflow-Inc/oneflow/pull/6280

• dataloader简介
• dataloader原理
• dataloader工作流程
• multiprocessing dataloader工作原理

2

dataloader原理

核心组建

• Dataloader

• Dataset

• Sampler

• Fetcher

使用示例

1.MNIST

transform=transforms.Compose([
        transforms.ToTensor(),
        transforms.Normalize((0.1307,), (0.3081,))
        ])
dataset1 = datasets.MNIST('../data', train=True, download=True,
                          transform=transform)
dataset2 = datasets.MNIST('../data', train=False,
                          transform=transform)
train_loader = torch.utils.data.DataLoader(dataset1,**train_kwargs)
test_loader = torch.utils.data.DataLoader(dataset2, **test_kwargs)








   def __getitem__(self, index: int) -> Tuple[Any, Any]:
    """
        Args:
            index (int): Index
        Returns:
            tuple: (image, target) where target is index of the target class.
        """
    img, target = self.data[index], int(self.targets[index])

    # doing this so that it is consistent with all other datasets
    # to return a PIL Image
    img = Image.fromarray(img.numpy(), mode='L')

    if self.transform is not None:
        img = self.transform(img)

        if self.target_transform is not None:
            target = self.target_transform(target)

            return img, target












   def train(args, model, device, train_loader, optimizer, epoch):
    model.train()
    for batch_idx, (data, target) in enumerate(train_loader):
        data, target = data.to(device), target.to(device)
        optimizer.zero_grad()
        output = model(data)
        ....





2.ImageNet








   train_dataset = datasets.ImageFolder(
        traindir,
        transforms.Compose([
            transforms.RandomResizedCrop(224),
            transforms.RandomHorizontalFlip(),
            transforms.ToTensor(),
            normalize,
        ]))

    if args.distributed:
        train_sampler = torch.utils.data.distributed.DistributedSampler(train_dataset)
    else:
        train_sampler = None

    train_loader = torch.utils.data.DataLoader(
        train_dataset, batch_size=args.batch_size, shuffle=(train_sampler is None),
        num_workers=args.workers, pin_memory=True, sampler=train_sampler)

    val_loader = torch.utils.data.DataLoader(
        datasets.ImageFolder(valdir, transforms.Compose([
            transforms.Resize(256),
            transforms.CenterCrop(224),
            transforms.ToTensor(),
            normalize,
        ])),
        batch_size=args.batch_size, shuffle=False,
        num_workers=args.workers, pin_memory=True)












   class ImageFolder(DatasetFolder):
    r"""A generic data loader where the images are arranged in this way by default:
    .. code-block:: shell
        root/dog/xxx.png
        root/dog/xxy.png
        root/dog/[...]/xxz.png
        root/cat/123.png
        root/cat/nsdf3.png
        root/cat/[...]/asd932_.png
    This class inherits from :class:`~vision.datasets.DatasetFolder` so
    the same methods can be overridden to customize the dataset.
    Args:
        root (string): Root directory path.
        transform (callable, optional): A function/transform that  takes in an PIL image
            and returns a transformed version. E.g, ``transforms.RandomCrop``
        target_transform (callable, optional): A function/transform that takes in the
            target and transforms it.
        loader (callable, optional): A function to load an image given its path.
        is_valid_file (callable, optional): A function that takes path of an Image file
            and check if the file is a valid file (used to check of corrupt files)
     Attributes:
        classes (list): List of the class names sorted alphabetically.
        class_to_idx (dict): Dict with items (class_name, class_index).
        imgs (list): List of (image path, class_index) tuples
    """

    def __init__(
        self,
        root: str,
        transform: Optional[Callable] = None,
        target_transform: Optional[Callable] = None,
        loader: Callable[[str], Any] = default_loader,
        is_valid_file: Optional[Callable[[str], bool]] = None,
    ):
        super(ImageFolder, self).__init__(
            root,
            loader,
            IMG_EXTENSIONS if is_valid_file is None else None,
            transform=transform,
            target_transform=target_transform,
            is_valid_file=is_valid_file,
        )
        self.imgs = self.samples





• root：图片文件夹路径

• transform：对经过loader读取到的PIL图片，经过哪些transform处理，如上述的Resize、CenterCrop等

• loader：一个用于根据path加载图片的图像加载器，通常默认的loader是PIL








   def __getitem__(self, index: int) -> Tuple[Any, Any]:
    """
        Args:
            index (int): Index
        Returns:
            tuple: (sample, target) where target is class_index of the target class.
        """
    path, target = self.samples[index]
    sample = self.loader(path)
    if self.transform is not None:
        sample = self.transform(sample)
        if self.target_transform is not None:
            target = self.target_transform(target)

            return sample, target












   for i, (images, target) in enumerate(train_loader):
        # measure data loading time
        data_time.update(time.time() - end)

        if args.gpu is not None:
            images = images.cuda(args.gpu, non_blocking=True)
        if torch.cuda.is_available():
            target = target.cuda(args.gpu, non_blocking=True)
        .....





3

dataloader工作流程








   class Dataset(Generic[T_co]):
    r"""An abstract class representing a :class:`Dataset`.
    All datasets that represent a map from keys to data samples should subclass
    it. All subclasses should overwrite :meth:`__getitem__`, supporting fetching a
    data sample for a given key. Subclasses could also optionally overwrite
    :meth:`__len__`, which is expected to return the size of the dataset by many
    :class:`~flow.utils.data.Sampler` implementations and the default options
    of :class:`~flow.utils.data.DataLoader`.
    .. note::
      :class:`~flow.utils.data.DataLoader` by default constructs a index
      sampler that yields integral indices.  To make it work with a map-style
      dataset with non-integral indices/keys, a custom sampler must be provided.
    """

    def __getitem__(self, index) -> T_co:
        raise NotImplementedError

    def __add__(self, other: "Dataset[T_co]") -> "ConcatDataset[T_co]":
        return ConcatDataset([self, other])












   class DataLoader(Generic[T_co]):
    def __init__(
            self,
            dataset: Dataset[T_co],
            batch_size: Optional[int] = 1,
            shuffle: bool = False,
            sampler: Optional[Sampler[int]] = None,
            batch_sampler: Optional[Sampler[Sequence[int]]] = None,
            num_workers: int = 0,
            collate_fn: Optional[_collate_fn_t] = None,
            drop_last: bool = False,
            timeout: float = 0,
            worker_init_fn: Optional[_worker_init_fn_t] = None,
            multiprocessing_context=None,
            generator=None,
            *,
            prefetch_factor: int = 2,
            persistent_workers: bool = False
        ):

    ...
    ...
# We quote '_BaseDataLoaderIter' since it isn't defined yet and the definition can't be moved up
    # since '_BaseDataLoaderIter' references 'DataLoader'.
    def __iter__(self) -> "_BaseDataLoaderIter":
        # When using a single worker the returned iterator should be
        # created everytime to avoid reseting its state
        # However, in the case of a multiple workers iterator
        # the iterator is only created once in the lifetime of the
        # DataLoader object so that workers can be reused
        if self.persistent_workers and self.num_workers > 0:
            if self._iterator is None:
                self._iterator = self._get_iterator()
            else:
                self._iterator._reset(self)
            return self._iterator
        else:
            return self._get_iterator()

def _get_iterator(self) -> "_BaseDataLoaderIter":
        if self.num_workers == 0 or self.num_workers == 1:
            return _SingleProcessDataLoaderIter(self)
        else:
            self.check_worker_number_rationality()
            return _MultiProcessingDataLoaderIter(self)





• 在单进程下，即_SingleProcessDataLoaderIter；

• 多进程下，即_MultiProcessingDataLoaderIter，他们都继承自_BaseDataLoaderIter








   class _BaseDataLoaderIter(object):
    def __init__(self, loader: DataLoader) -> None:
        self._dataset = loader.dataset
        self._dataset_kind = loader._dataset_kind
        self._IterableDataset_len_called = loader._IterableDataset_len_called
        self._auto_collation = loader._auto_collation
        self._drop_last = loader.drop_last
        self._index_sampler = loader._index_sampler
        self._num_workers = loader.num_workers
        self._prefetch_factor = loader.prefetch_factor
        self._pin_memory = False
        self._timeout = loader.timeout
        self._collate_fn = loader.collate_fn
        self._sampler_iter = iter(self._index_sampler)
        self._base_seed = flow.tensor([0], dtype=flow.int64).uniform_().numpy().item()
        # TODO: flow.empty()
        # self._base_seed = flow.empty((), dtype=flow.int64).random_(generator=loader.generator).item()
        self._persistent_workers = loader.persistent_workers
        self._num_yielded = 0
        self._profile_name = "enumerate(DataLoader)#{}.__next__".format(
            self.__class__.__name__
        )

    def __iter__(self) -> "_BaseDataLoaderIter":
        return self

    def _reset(self, loader, first_iter=False):
        self._sampler_iter = iter(self._index_sampler)
        self._num_yielded = 0
        self._IterableDataset_len_called = loader._IterableDataset_len_called

    def _next_index(self):
        return next(self._sampler_iter)  # may raise StopIteration

    def _next_data(self):
        raise NotImplementedError

    def __next__(self) -> Any:
        if self._sampler_iter is None:
            self._reset()
        data = self._next_data()
        self._num_yielded += 1
        if (
            self._dataset_kind == _DatasetKind.Iterable
            and self._IterableDataset_len_called is not None
            and self._num_yielded > self._IterableDataset_len_called
        ):
            warn_msg = (
                "Length of IterableDataset {} was reported to be {} (when accessing len(dataloader)), but {} "
                "samples have been fetched. "
            ).format(self._dataset, self._IterableDataset_len_called, self._num_yielded)
            if self._num_workers > 1:
                warn_msg += "Multiprocessing dataloader is not support yet!"
            warnings.warn(warn_msg)
        return data

    def __len__(self) -> int:
        return len(self._index_sampler)

    def __getstate__(self):
        raise NotImplementedError("{} cannot be pickled", self.__class__.__name__)


class _SingleProcessDataLoaderIter(_BaseDataLoaderIter):
    def __init__(self, loader):
        super(_SingleProcessDataLoaderIter, self).__init__(loader)
        assert self._timeout == 0
        assert 0 <= self._num_workers <= 1

        self._dataset_fetcher = _DatasetKind.create_fetcher(
            self._dataset_kind,
            self._dataset,
            self._auto_collation,
            self._collate_fn,
            self._drop_last,
        )

    def _next_data(self):
        index = self._next_index()  # may raise StopIteration
        if self._pin_memory:
            raise NotImplementedError("Dataloader pin memory is not support yet!")
        return self._dataset_fetcher.fetch(index)





• index = self._next_index()通过Sampler获取此次迭代的数据集索引；

• self._dataset_fetcher.fetch(index)Fetcher根据index索引取相应的数据。








   class _MapDatasetFetcher(_BaseDatasetFetcher):
    def __init__(self, dataset, auto_collation, collate_fn, drop_last):
        super(_MapDatasetFetcher, self).__init__(
            dataset, auto_collation, collate_fn, drop_last
        )

    def fetch(self, possibly_batched_index):
        if self.auto_collation:
            data = [self.dataset[idx] for idx in possibly_batched_index]
        else:
            data = self.dataset[possibly_batched_index]
        return self.collate_fn(data)





• data = [self.dataset[idx] for idx in possibly_batched_index]

• return self.collate_fn(data)

4

multiprocessing dataloader工作原理

原理








   # prime the prefetch loop
for _ in range(self._prefetch_factor * self._num_workers):
    self._try_put_index()





工作流程








   def _next_data(self):
  # DataLoaderIter通过此方法获取每个iter的数据，主要调用_get_data实现

def _get_data(self):
  # _get_data方法中，主要通过调用_try_get_data()获取数据

def _try_get_data(self, timeout=_utils.MP_STATUS_CHECK_INTERVAL):
  # 从主进程的_data_queue中获取数据
  ...
  try:
      data = self._data_queue.get(timeout=timeout)
      return (True, data)
  except Exception as e:
     ...

def _process_data(self, data):
  # 主要工作即：1.通过_try_put_index()来将下一个iter的index放入一个活跃的worker进程中
  # 2.同时标记_rcvd_idx，使其增加1。
  self._rcvd_idx += 1
  self._try_put_index()
  if isinstance(data, ExceptionWrapper):
    data.reraise()
    return data

def _try_put_index(self):
  # 主要工作即遍历所有workers，找到第一个活跃的worker(worker_queue_idx标识)
  # 将index和_send_idx信息放入此worker的index_queue中
  # 每个worker拥有独立的index_queue，收到index_queue的信息后即开始工作
  assert self._tasks_outstanding < self._prefetch_factor * self._num_workers
  try:
    index = self._next_index()
    except StopIteration:
      return
    for _ in range(self._num_workers):  # find the next active worker, if any
      worker_queue_idx = next(self._worker_queue_idx_cycle)
      if self._workers_status[worker_queue_idx]:
        break
    else:
      # not found (i.e., didn't break)
      return

    self._index_queues[worker_queue_idx].put((self._send_idx, index))
    self._task_info[self._send_idx] = (worker_queue_idx,)
    self._tasks_outstanding += 1
    self._send_idx += 1












   while watchdog.is_alive():
            try:
                r = index_queue.get(timeout=MP_STATUS_CHECK_INTERVAL)
            except queue.Empty:
                continue
            if isinstance(r, _ResumeIteration):
                # Acknowledge the main process
                data_queue.put((r, None))
                iteration_end = False
                # Recreate the fetcher for worker-reuse policy
                fetcher = _DatasetKind.create_fetcher(
                    dataset_kind, dataset, auto_collation, collate_fn, drop_last
                )
                continue
            elif r is None:
                # Received the final signal
                assert done_event.is_set() or iteration_end
                break
            elif done_event.is_set() or iteration_end:
                # `done_event` is set. But I haven't received the final signal
                # (None) yet. I will keep continuing until get it, and skip the
                # processing steps.
                continue
            idx, index = r
            data: Union[_IterableDatasetStopIteration, ExceptionWrapper]

            if init_exception is not None:
                data = init_exception
                init_exception = None
            else:
                try:
                    data = fetcher.fetch(index)
                except Exception as e:
                    if (
                        isinstance(e, StopIteration)
                        and dataset_kind == _DatasetKind.Iterable
                    ):
                        data = _IterableDatasetStopIteration(worker_id)
                        # Set `iteration_end`
                        #   (1) to save future `next(...)` calls, and
                        #   (2) to avoid sending multiple `_IterableDatasetStopIteration`s.
                        iteration_end = True
                    else:
                        # It is important that we don't store exc_info in a variable.
                        # `ExceptionWrapper` does the correct thing.
                        # See NOTE [ Python Traceback Reference Cycle Problem ]
                        data = ExceptionWrapper(
                            where="in DataLoader worker process {}".format(worker_id)
                        )
            data_queue.put((idx, data))
            del data, idx, index, r  # save memory
    except KeyboardInterrupt:
        # Main process will raise KeyboardInterrupt anyways.
        pass





• OneFlow v0.5.0正式上线

• 计算机架构史上的一次伟大失败


• OneFlow中的错误处理：Maybe

• 最理想的点到点通信库究竟是怎样的

• 玩转大模型，是时候展示你真正的技术了

• 如何实现比PyTorch快6倍的Permute/Transpose算子

点击“ 阅读原文 ” ，欢迎下载体验OneFlow新一代开源深度学习框架

---
