主流大数据技术全体系参数与搭建与后台代码工程框架的编写（百分之70）

之前查阅源码啊，性能测试啊调优啊。。基本告一段落，项目也接近尾声，那么整理下spark所有配置参数与优化策略，方便以后开发与配置： Spark安装配置与代码框架 spark-default.conf 配置 spark.executor.instance 参数，向Yarn申请创建的资源池实例数 spark.executor.cores 参数，每个container中所包含的core数量 spark.executor.memory 参数，每个资源池所具有的内存数 spark.dirver.memory 参数，driver端所占用的资源数 spark.storage.memoryFraction 参数，用于cache数据与计算数据集的内存使用比例 spark.kryoserializer.buffer.max 参数，序列化最大值，默认64M spark.shuffle.consolidateFiles 参数，shuffle是否合并文件 spark.rdd.compress 参数，rdd是否进行压缩 spark.sql.shuffle.partitions 参数，shuffle过程中所创建的partition个数 spark.reducer.maxSizeInFlight 参数，设置shuffle read task的buffer缓冲大小，它将决定每次数据从远程的executors中拉取大小。这个拉取过程是由5个并行的request,从不同的executor中拉取过来,从而提升了fetch的效率。 spark.shuffle.io.retryWait 参数，每次拉取数据的等待间隔 spark.shuffle.manage参数,使用hash，同时与参数spark.shuffle.consolidateFiles true并用。因为不需要对中间结果进行排序，同时合并中间文件的个数，从而减少打开文件的性能消耗,在spark2.0.2中不可直接配置hash，会报错，其他优化参数包括：Sort Shuffle、Tungsten Sort，这里我们要根据数据量进行选择，优缺点请参考本博客《Spark Shuffle详细过程》 spark.executor.heartbeatInterval 参数，与driver的通讯间隔，使driver知道executor有木有挂 spark.driver.maxResultSize 参数，所有分区的序列化结果的总大小限制 spark.yarn.am.cores 参数，在yarn-client模式下，申请Yarn App Master所用的CPU核数 spark.master 参数，选用的模式 spark.task.maxFailures 参数，task失败多少次后丢弃job（防止因为网络IO等问题失败，重新拉取） spark.shuffle.file.buffer 参数，会增大Map任务的写磁盘前的cache缓存 spark-env.sh 配置 export HADOOP_CONF_DIR 参数，配置hadoop所在配置文件路径 export HADOOP_HOME 参数，配置hadoop Client的所在路径 export JAVA_HOME 参数，配置JAVA的环境变量地址 export SPARK_YARN_APP_NAME 参数，配置application的名称 export SPARK_LOG_DIR 参数，配置Spark log的输出路径 export SPARK_PID_DIR 参数，配置spark的Pid输出路径将hive-site.xml文件放入spark的conf下修改spark thrift port，使其与hive的thrift的port分离开来，同时配置mysql的数据源，因为hive的meta信息存在mysql中，以及配置meta指定的hdfs路径： <property> <name>hive.server2.thrift.port</name> <value>10000</value> <description>Port number of HiveServer2 Thrift interface. Can be overridden by setting $HIVE_SERVER2_THRIFT_PORT</description></property> <property> <name>hive.metastore.warehouse.dir</name> <value>/user/hive/warehouse</value></property> <property> <name>javax.jdo.option.ConnectionDriverName</name> <value>com.mysql.jdbc.Driver</value> <description>Driver class name for a JDBC metastore</description></property> <property> <name>javax.jdo.option.ConnectionUserName</name> <value>root</value> <description>username to use against metastore database</description></property> <property> <name>javax.jdo.option.ConnectionPassword</name> <value>root</value> <description>password to use against metastore database</description></property> Spark动态资源分配测试： spark.dynamicAllocation.cachedExecutorIdleTimeout 360000000 如果executor中有数据则不移除 spark.dynamicAllocation.executorIdleTimeout 60s executor空闲时间达到规定值，则将该executor移除 spark.dynamicAllocation.initialExecutors 3 如果所有的executor都移除了，重新请求时启动的初始executor数 spark.dynamicAllocation.maxExecutors 30 能够启动的最大executor数目 spark.dynamicAllocation.minExecutors 1 能够启动的最小executor数目 spark.dynamicAllocation.schedulerBacklogTimeout 1s task等待运行时间超过该值后开始启动executor spark.dynamicAllocation.enabled True 开启动态参数配置 spark.dynamicAllocation.sustainedSchedulerBacklogTimeout 1s 启动executor的时间间隔启动脚本： /usr/local/spark-1.6.1/sbin/start-thriftserver.sh \ --conf spark.shuffle.service.enabled=true \ --conf spark.dynamicAllocation.enabled=true \ --conf spark.dynamicAllocation.minExecutors=2 \ --conf spark.dynamicAllocation.maxExecutors=30 \ --conf spark.dynamicAllocation.sustainedSchedulerBacklogTimeout = 5s \ --conf spark.dynamicAllocation.schedulerBacklogTimeout=1s \ --conf spark.dynamicAllocation.initialExecutors=2 \ --conf spark.dynamicAllocation.executorIdleTimeout=60s \ --conf spark.dynamicAllocation.cachedExecutorIdleTimeout=360000000s \ --conf spark.driver.memory=50g 代码框架：首先，我们引入需要依赖的包括hadoop、spark、hbase等jar包，pom.xml配置如下： <project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/maven-v4_0_0.xsd"> <modelVersion>4.0.0</modelVersion> <groupId>sparkApp</groupId> <artifactId>sparkApp</artifactId> <version>1.0-SNAPSHOT</version> <inceptionYear>2008</inceptionYear> <properties> <scala.version>2.10.0</scala.version> <spring.version>4.0.2.RELEASE</spring.version> <hadoop.version>2.6.0</hadoop.version> <jedis.version>2.8.1</jedis.version> </properties> <repositories> <repository> <id>scala-tools.org</id> <name>Scala-Tools Maven2 Repository</name> <url>http://scala-tools.org/repo-releases</url> </repository> </repositories> <pluginRepositories> <pluginRepository> <id>scala-tools.org</id> <name>Scala-Tools Maven2 Repository</name> <url>http://scala-tools.org/repo-releases</url> </pluginRepository> </pluginRepositories> <dependencies> <dependency> <groupId>org.scala-lang</groupId> <artifactId>scala-library</artifactId> <version>${scala.version}</version> </dependency> <dependency> <groupId>junit</groupId> <artifactId>junit</artifactId> <version>4.4</version> <scope>test</scope> </dependency>  <dependency> <groupId>org.apache.spark</groupId> <artifactId>spark-core_2.10</artifactId> <version>1.6.1</version> </dependency>  <dependency> <groupId>org.apache.spark</groupId> <artifactId>spark-sql_2.10</artifactId> <version>1.6.1</version> </dependency> <dependency> <groupId>org.apache.spark</groupId> <artifactId>spark-mllib_2.10</artifactId> <version>1.6.1</version> </dependency> <dependency> <groupId>org.apache.spark</groupId> <artifactId>spark-hive_2.10</artifactId> <version>1.6.1</version> </dependency>   <dependency> <groupId>org.apache.hadoop</groupId> <artifactId>hadoop-hdfs</artifactId> <version>${hadoop.version}</version> <exclusions> <exclusion> <groupId>commons-logging</groupId> <artifactId>commons-logging</artifactId> </exclusion> <exclusion> <groupId>log4j</groupId> <artifactId>log4j</artifactId> </exclusion> <exclusion> <groupId>org.slf4j</groupId> <artifactId>slf4j-log4j12</artifactId> </exclusion> <exclusion> <groupId>org.slf4j</groupId> <artifactId>slf4j-api</artifactId> </exclusion> <exclusion> <groupId>javax.servlet.jsp</groupId> <artifactId>jsp-api</artifactId> </exclusion> </exclusions> </dependency> <dependency> <groupId>org.apache.hadoop</groupId> <artifactId>hadoop-common</artifactId> <version>${hadoop.version}</version> </dependency>   <dependency> <groupId>org.apache.hbase</groupId> <artifactId>hbase-server</artifactId> <version>1.0.2</version> </dependency> <dependency> <groupId>org.apache.htrace</groupId> <artifactId>htrace-core</artifactId> <version>3.1.0-incubating</version> </dependency> <dependency> <groupId>org.apache.hbase</groupId> <artifactId>hbase-client</artifactId> <version>1.0.2</version> </dependency> <dependency> <groupId>org.apache.hbase</groupId> <artifactId>hbase-common</artifactId> <version>1.0.2</version> </dependency> <dependency> <groupId>org.apache.hbase</groupId> <artifactId>hbase-protocol</artifactId> <version>1.0.2</version> </dependency>  <dependency> <groupId>com.google.guava</groupId> <artifactId>guava</artifactId> <version>11.0.2</version> </dependency> <dependency> <groupId>org.slf4j</groupId> <artifactId>slf4j-api</artifactId> <version>1.7.12</version> </dependency>  <dependency> <groupId>redis.clients</groupId> <artifactId>jedis</artifactId> <version>${jedis.version}</version> </dependency>  <dependency> <groupId>org.apache.commons</groupId> <artifactId>commons-lang3</artifactId> <version>3.1</version> </dependency> <dependency> <groupId>org.apache.commons</groupId> <artifactId>commons-pool2</artifactId> <version>2.3</version> </dependency> <dependency> <groupId>mysql</groupId> <artifactId>mysql-connector-java</artifactId> <version>5.1.26</version> </dependency>  <dependency> <groupId>io.netty</groupId> <artifactId>netty-all</artifactId> <version>5.0.0.Alpha1</version> </dependency>  <dependency> <groupId>org.apache.hive</groupId> <artifactId>hive-jdbc</artifactId> <version>2.1.0</version> </dependency> <dependency> <groupId>org.apache.hive</groupId> <artifactId>hive-service</artifactId> <version>1.2.1</version> </dependency> </dependencies> <build>  <plugins> <plugin> <groupId>org.scala-tools</groupId> <artifactId>maven-scala-plugin</artifactId> <executions> <execution> <goals> <goal>compile</goal> <goal>testCompile</goal> </goals> </execution> </executions> <configuration> <scalaVersion>${scala.version}</scalaVersion> <args> <arg>-target:jvm-1.5</arg> </args> </configuration> </plugin> <plugin> <groupId>org.apache.maven.plugins</groupId> <artifactId>maven-eclipse-plugin</artifactId> <configuration> <downloadSources>true</downloadSources> <buildcommands> <buildcommand>ch.epfl.lamp.sdt.core.scalabuilder</buildcommand> </buildcommands> <additionalProjectnatures> <projectnature>ch.epfl.lamp.sdt.core.scalanature</projectnature> </additionalProjectnatures> <classpathContainers> <classpathContainer>org.eclipse.jdt.launching.JRE_CONTAINER</classpathContainer> <classpathContainer>ch.epfl.lamp.sdt.launching.SCALA_CONTAINER</classpathContainer> </classpathContainers> </configuration> </plugin> </plugins> </build> <reporting> <plugins> <plugin> <groupId>org.scala-tools</groupId> <artifactId>maven-scala-plugin</artifactId> <configuration> <scalaVersion>${scala.version}</scalaVersion> </configuration> </plugin> </plugins> </reporting> </project> 然后将集群中hive-site.xml、hdfs-site.xml、hbase-site.xml引入项目中。编写HBase公共方法（部分代码）： 1 package hbase 2 3 import java.util.{Calendar, Date} 4 5 import org.apache.hadoop.hbase.HBaseConfiguration 6 import org.apache.hadoop.hbase.client.{Result, Scan} 7 import org.apache.hadoop.hbase.filter._ 8 import org.apache.hadoop.hbase.io.ImmutableBytesWritable 9 import org.apache.hadoop.hbase.mapreduce.TableInputFormat 10 import org.apache.hadoop.hbase.protobuf.ProtobufUtil 11 import org.apache.hadoop.hbase.util.{Base64, Bytes} 12 import org.apache.spark.{Logging, SparkContext} 13 import org.apache.spark.rdd.RDD 14 import org.slf4j.{Logger, LoggerFactory} 15 16 /** 17 * Created by ysy on 2016/11/6. 18 */ 19 object HBaseTableHelper extends Serializable { 20 21 val logger: Logger = LoggerFactory.getLogger(HBaseTableHelper.getClass) 22 23 //根据timestramp过滤加载Hbase数据 24 def tableInitByTime(sc : SparkContext,tablename:String,columns :String,fromdate: Date,todate:Date):RDD[(ImmutableBytesWritable,Result)] = { 25 val configuration = HBaseConfiguration.create() 26 configuration.set(TableInputFormat.INPUT_TABLE, tablename) 27 28 val scan = new Scan 29 scan.setTimeRange(fromdate.getTime,todate.getTime) 30 val column = columns.split(",") 31 for(columnName <- column){ 32 scan.addColumn("f1".getBytes, columnName.getBytes) 33 } 34 configuration.set(TableInputFormat.SCAN, convertScanToString(scan)) 35 val hbaseRDD = sc.newAPIHadoopRDD(configuration, classOf[TableInputFormat], classOf[org.apache.hadoop.hbase.io.ImmutableBytesWritable], classOf[org.apache.hadoop.hbase.client.Result]) 36 logger.info("-------count-------" + hbaseRDD.count() + "------------------") 37 hbaseRDD 38 } 39 40 def convertScanToString(scan : Scan) = { 41 val proto = ProtobufUtil.toScan(scan) 42 Base64.encodeBytes(proto.toByteArray) 43 } 44 45 //根据时间条件filter数据 46 def tableInitByFilter(sc : SparkContext,tablename : String,columns : String,time : String) : RDD[(ImmutableBytesWritable,Result)] = { 47 val configuration = HBaseConfiguration.create() 48 configuration.set(TableInputFormat.INPUT_TABLE,tablename) 49 val filter: Filter = new RowFilter(CompareFilter.CompareOp.GREATER_OR_EQUAL, new SubstringComparator(time)) 50 val scan = new Scan 51 scan.setFilter(filter) 52 val column = columns.split(",") 53 for(columnName <- column){ 54 scan.addColumn("f1".getBytes, columnName.getBytes) 55 } 56 val hbaseRDD = sc.newAPIHadoopRDD(configuration, classOf[TableInputFormat], classOf[org.apache.hadoop.hbase.io.ImmutableBytesWritable], classOf[org.apache.hadoop.hbase.client.Result]) 57 logger.info("-------count-------" + hbaseRDD.count() + "------------------") 58 hbaseRDD 59 } 60 61 def HBaseTableInit(): Unit ={ 62 63 } 64 65 def hbaseToHiveTable(): Unit ={ 66 67 } 68 69 //前N天的时间戳获取 70 def getPassDays(beforeDay : Int): Date ={ 71 val calendar = Calendar.getInstance() 72 var year = calendar.get(Calendar.YEAR) 73 var dayOfYear = calendar.get(Calendar.DAY_OF_YEAR) 74 var j = 0 75 for(i <- 0 to beforeDay){ 76 calendar.set(Calendar.DAY_OF_YEAR, dayOfYear - j); 77 if (calendar.get(Calendar.YEAR) < year) { 78 //跨年了 79 j = 1; 80 //更新标记年 81 year = year + 1; 82 //重置日历 83 calendar.set(year,Calendar.DECEMBER,31); 84 //重新获取dayOfYear 85 dayOfYear = calendar.get(Calendar.DAY_OF_YEAR); 86 }else{ 87 j = j + 1 88 } 89 } 90 calendar.getTime() 91 } 92 93 //根据startRow与endRow进行过滤 94 def scanHbaseByStartAndEndRow(sc : SparkContext,startRow : String,stopRow : String,tableName : String) : RDD[(ImmutableBytesWritable,Result)] ={ 95 val configuration = HBaseConfiguration.create() 96 val scan = new Scan() 97 scan.setCacheBlocks(false) 98 scan.setStartRow(Bytes.toBytes(startRow)) 99 scan.setStopRow(Bytes.toBytes(stopRow)) 100 val filterList = new FilterList() 101 filterList.addFilter(new KeyOnlyFilter()) 102 filterList.addFilter(new InclusiveStopFilter(Bytes.toBytes(stopRow))) 103 scan.setFilter(filterList) 104 configuration.set(TableInputFormat.INPUT_TABLE,tableName) 105 configuration.set(TableInputFormat.SCAN, convertScanToString(scan)) 106 val hbaseRDD = sc.newAPIHadoopRDD(configuration, classOf[TableInputFormat], classOf[org.apache.hadoop.hbase.io.ImmutableBytesWritable], classOf[org.apache.hadoop.hbase.client.Result]) 107 logger.info("-------ScanHbaseCount-------" + hbaseRDD.count() + "------------------") 108 hbaseRDD 109 } 110 111 } 编写hive公共方法（部分代码）： 1 package hive 2 3 import org.apache.spark.{Logging, SparkContext} 4 import org.apache.spark.rdd.RDD 5 import org.apache.spark.sql.Row 6 import org.apache.spark.sql.hive.HiveContext 7 import org.apache.spark.sql.types.{StringType, StructField, StructType} 8 9 /** 10 * Created by uatcaiwy on 2016/11/6. 11 */ 12 object HiveTableHelper extends Logging { 13 14 def hiveTableInit(sc:SparkContext): HiveContext ={ 15 val sqlContext = new HiveContext(sc) 16 sqlContext 17 } 18 19 def writePartitionTable(HCtx:HiveContext,inputRdd:RDD[Row],tabName:String,colNames:String):Unit ={ 20 val schema = StructType( 21 colNames.split(" ").map(fieldName => StructField(fieldName,StringType,true)) 22 ) 23 val table = colNames.replace(" dt","").split(" ").map(name => name + " String").toList.toString().replace("List(","").replace(")","") 24 val df = HCtx.createDataFrame(inputRdd,schema) 25 df.show(20) 26 logInfo("----------------------------------begin write table-----------------------------------") 27 val temptb = "temp" + tabName 28 HCtx.sql("drop table if exists " + tabName) 29 df.registerTempTable(temptb) 30 HCtx.sql("CREATE EXTERNAL TABLE if not exists " + tabName +" ("+ table+ ") PARTITIONED BY (`dt` string) ROW FORMAT DELIMITED FIELDS TERMINATED BY '|' STORED AS INPUTFORMAT 'org.apache.hadoop.mapred.SequenceFileIn putFormat' OUTPUTFORMAT 'org.apache.hadoop.hive.ql.io.HiveSequenceFileOutputFormat'") 31 HCtx.sql("set hive.exec.dynamic.partition.mode = nonstrict") 32 HCtx.sql("insert overwrite table " + tabName + " partition(`dt`)" + " select * from " + temptb) 33 } 34 } 读取hdfs文件,有时我们需要根据文件的编码来读取，否则会乱码，并改变编码公共方法： 1 package importSplitFiletoHive 2 3 import org.apache.hadoop.io.{LongWritable, Text} 4 import org.apache.hadoop.mapred.TextInputFormat 5 import org.apache.spark.SparkContext 6 import org.apache.spark.rdd.RDD 7 8 /** 9 * Created by ysy on 2016/12/7. 10 */ 11 object changeEncode { 12 13 def changeFileEncoding(sc:SparkContext,path:String,encode : String):RDD[String]={ 14 sc.hadoopFile(path,classOf[TextInputFormat],classOf[LongWritable],classOf[Text],1) 15 .map(p => new String(p._2.getBytes,0,p._2.getLength,encode)) 16 } spark进行xml解析（部分代码）： 1 import hive.HiveTableHelper 2 import org.apache.spark.Logging 3 import org.apache.spark.rdd.RDD 4 import org.apache.spark.sql.Row 5 import org.apache.spark.sql.hive.HiveContext 6 import org.apache.spark.sql.types.{StringType, StructField, StructType} 7 import org.slf4j.LoggerFactory 8 9 import scala.xml._ 10 11 object xmlParse extends Logging{ 12 val schemaString = "column1,column2...." 13 def getPBOC_V1_F1(HCtx:HiveContext,rdd:RDD[String],outputTablename:String):Unit = { 14 val tbrdd = rdd.filter(_.split("\t").length == 9) 15 .filter(_.split("\t")(8) != "RESULTS") 16 .map(data => { 17 val sp = data.split("\t") 18 val dt = sp(5).substring(0, 10).replaceAll("-", "") 19 ((sp(0), sp(1), sp(2), sp(3), sp(4), sp(5), sp(6), "RN"), sp(8), dt) 20 }).filter(_._2 != "") 21 .filter(_._2.split("<").length > 2) 22 .filter(data => !(data._2.indexOf("SingleQueryResultMessage0009") == -1 || data._2.indexOf("ReportMessage") == -1)) 23 .map(data => { 24 val xml = if (XML.loadString(data._2) != null) XML.loadString(data._2) else null 25 logDebug("%%%%%%%%%%%%%%%%%%finding xml-1:" + xml + "%%%%%%%%%%%%%%%%%%") 26 val column1 = if ((xml \ "PBOC" \ "TYPE") != null) (xml \ "PBOC" \ "TYPE").text else "null" 27 val column2 = if ((xml \ "HEAD" \ "VER") != null) (xml \ "HEAD" \ "VER").text else "null" 28 val column3 = if ((xml \ "HEAD" \ "SRC") != null) (xml \ "HEAD" \ "SRC").text else "null" 29 val column4 = if ((xml \ "HEAD" \ "DES") != null) (xml \ "HEAD" \ "DES").text else "null" 30 .... 31 (data._1,column1,column2,column3...) 32 }) 33 ROW(....) 34 HiveTableHelper.writePartitionTable(HCtx, tbrdd, outputTablename, schemaString) Redis编码公共方法（部分代码）： 1 package redis 2 3 import org.slf4j.{Logger, LoggerFactory} 4 import redis.clients.jedis.{Jedis, JedisPool, JedisPoolConfig} 5 6 import scala.collection.mutable.ArrayBuffer 7 import scala.util.Random 8 9 /** 10 * Created by ysy on 2016/11/21. 11 */ 12 object RedisClient extends Serializable{ 13 val logger: Logger = LoggerFactory.getLogger(RedisClient.getClass) 14 @transient private var jedisPool : JedisPool = null 15 private var jedisPoolList = new ArrayBuffer[JedisPool] 16 private val poolSize = 0 17 makePool 18 19 def makePool() ={ 20 val pc = new PropConfig("redis.properties"); 21 if(jedisPool == null){ 22 val poolConfig : JedisPoolConfig = new JedisPoolConfig 23 poolConfig.setMaxIdle(pc.getProperty("redis.pool.maxActive").toInt) 24 poolConfig.setMaxTotal(pc.getProperty("redis.pool.maxActive").toInt) 25 poolConfig.setMaxWaitMillis(pc.getProperty("redis.pool.maxWait").toInt) 26 poolConfig.setTestOnBorrow(pc.getProperty("redis.pool.testOnBorrow").toBoolean) 27 poolConfig.setTestOnReturn(pc.getProperty("redis.pool.testOnReturn").toBoolean) 28 val hosts = pc.getProperty("redis.pool.servers").split(",") 29 .map(data => data.split(":")) 30 for(host <- hosts){ 31 jedisPool = new JedisPool(poolConfig,host(0),host(1).toInt,pc.getProperty("redis.server.timeout").toInt) 32 jedisPoolList += jedisPool 33 } 34 } 35 36 } 37 38 39 def getForString(key : String) : String = { 40 var value = "" 41 if(key != null && !key.isEmpty()){ 42 val jedis = getJedis 43 value = jedis.get(key) 44 } 45 value 46 } 47 48 def setForString(key : String,value : String) ={ 49 if(key != null && !key.isEmpty){ 50 var jedis = getJedis 51 jedis.set(key,value) 52 }else{ 53 54 } 55 } 56 57 def zexsist(key : String) : Boolean ={ 58 var flag = false 59 if(key != null && !key.isEmpty){ 60 val jedis = getJedis 61 62 val resultNum = jedis.zcard(key) 63 if("0".equals(resultNum.toLong)){ 64 flag = true 65 } 66 } 67 flag 68 } 69 70 def getJedis() : Jedis ={ 71 var ramNub = 0 72 if(poolSize == 1){ 73 ramNub = 0 74 }else{ 75 val random = new Random 76 ramNub = Math.abs(random.nextInt % 1) 77 } 78 jedisPool = jedisPoolList(ramNub) 79 jedisPool.getResource 80 } 81 82 def returnJedisResource(redis : Jedis): Unit ={ 83 if(redis != null){ 84 redis.close() 85 } 86 } 87 88 def close: Unit = { 89 for(jedisPool <- jedisPoolList){ 90 jedisPool.close 91 } 92 if(jedisPool!=null && !jedisPool.isClosed()){ 93 jedisPool.close 94 }else{ 95 jedisPool=null 96 } 97 } 98 99 } 详细就不写了，那么完整的工程框架搭建完毕：随后通过main方法创建sparkContext对象，开始数据分析与处理,在spark路径的bin目录下或者写成脚本文件执行: ./spark-submit --conf spark.ui.port=5566 --name "sparkApp" --master yarn-client --num-executors 3 --executor-cores 2 --executor-memory 10g --class impl.spark /usr/local/spark1.6.1/sparkApp/sparkApp.jar （注意：这里的配置参数会覆盖spark-default.conf中配置的变量，重新声明spark.ui.port的原因也是因为在同时启动spark的thrfit的时候，提交submit会造成UI占用的问题，至此spark完结） Hadoop安装配置与MapReduce代码框架安装： yum install gcc yum install gcc-c++ yum install make yum install autoconfautomake libtool cmake yum install ncurses-devel yum install openssl-devel 安装protoc(需用root用户) tar -xvf protobuf-2.5.0.tar.bz2 cd protobuf-2.5.0 ./configure --prefix=/opt/protoc/ make && make install 编译hadoop mvn clean package -Pdist,native -DskipTests -Dtar 编译完的hadoop在 /home/hadoop/ocdc/hadoop-2.6.0-src/hadoop-dist/target 路径下配置hosts文件 10.1.245.244 master 10.1.245.243 slave1 命令行输入 hostname master 免密码登录：执行命令生成密钥： ssh-keygen -t rsa -P "" 进入文件夹cd .ssh (进入文件夹后可以执行ls -a 查看文件) 将生成的公钥id_rsa.pub 内容追加到authorized_keys（执行命令：cat id_rsa.pub >> authorized_keys） core-site.xml <configuration>  <property> <name>fs.defaultFS</name> <value>hdfs://master</value> </property> <property> <name>io.file.buffer.size</name> <value>131072</value> </property>  <property> <name>hadoop.tmp.dir</name> <value>/home/hadoop/ocdc/hadoop-2.6.0/tmp</value> <description>Abasefor other temporary directories.</description> </property> <property> <name>hadoop.proxyuser.spark.hosts</name> <value>*</value> </property> <property> <name>hadoop.proxyuser.spark.groups</name> <value>*</value> </property> </configuration>  <property> <name>ha.zookeeper.quorum</name> <value>h4:2181,h5:2181,h6:2181</value> </property> </configuration> hdfs-site.xml <configuration> <property> <name>dfs.namenode.secondary.http-address</name> <value>master:9001</value> </property> <property> <name>dfs.namenode.name.dir</name> <value>/home/hadoop/ocdc/hadoop-2.6.0/name</value> </property> <property> <name>dfs.datanode.data.dir</name> <value>/home/hadoop/ocdc/hadoop-2.6.0/data</value> </property> <property> <name>dfs.replication</name> <value>3</value> </property> <property> <name>dfs.webhdfs.enabled</name> <value>true</value> </property> <property> <name>dfs.nameservices</name> <value>ns1</value> </property>  <property> <name>dfs.ha.namenodes.ns1</name> <value>nn1,nn2</value> </property> </configuration> yarn-site.xml <configuration>   <property> <name>yarn.nodemanager.aux-services</name> <value>mapreduce_shuffle</value> </property> <property> <name>yarn.nodemanager.aux-services.mapreduce.shuffle.class</name> <value>org.apache.hadoop.mapred.ShuffleHandler</value> </property> <property> <name>yarn.resourcemanager.address</name> <value>master:8032</value> </property> <property> <name>yarn.resourcemanager.scheduler.address</name> <value>master:8030</value> </property> <property> <name>yarn.resourcemanager.resource-tracker.address</name> <value>master:8035</value> </property> <property> <name>yarn.resourcemanager.admin.address</name> <value>master:8033</value> </property> <property> <name>yarn.resourcemanager.webapp.address</name> <value>master:8088</value> </property> <property> <name>yarn.nodemanager.resource.memory-mb</name> <value>16384</value> </property>  <property> <name>yarn.resourcemanager.hostname</name> <value>h3</value> </property> </configuration> mapred-site.xml <configuration> <property> <name>mapreduce.framework.name</name> <value>yarn</value> </property> <property> <name>mapreduce.jobhistory.address</name> <value>master:10020</value> </property> <property> <name>mapreduce.jobhistory.webapp.address</name> <value>master:19888</value> </property> <property> <name>yarn.scheduler.maximum-allocation-mb</name> <value>16384</value> </property> </configuration> 关于MapReduce，1年多前大家都觉得很神秘，其实就相当于在Map阶段或者Reduce阶段中，进行数据的处理，也可以在Map中读取写入hbase、redis都可以~其实就相当于在MapReduce中写业务处理逻辑，代码如下： 1 public static class Map extends MapReduceBase implments Mapper<LongWritable,Text,Text,IntWritable>{ 2 //设置常量1，用来形成<word,1>形式的输出 3 private fianll static IntWritable one = new IntWritable(1) 4 private Text word = new Text(); 5 6 public void map(LongWritable key,Text value,OutputCollector<Text,output,Reporter reporter) throws IOException{ 7 //hadoop执行map函数时为是一行一行的读取数据处理，有多少行，就会执行多少次map函数 8 String line = value.toString(); 9 //进行单词的分割，可以多传入进行分割的参数 10 StringTokenizer tokenizer = new StringTokenizer(line); 11 //遍历单词 12 while(tokenizer.hasMoreTokens()){ 13 //往Text中写入<word,1> 14 word.set(tokenizer.nextToken()); 15 output.collect(word,one); 16 } 17 } 18 } 19 //需要注意的是，reduce将相同key值(这里是word)的value值收集起来，形成<word,list of 1>的形式，再将这些1累加 20 public static class Reduce extends MapReduceBase implements Reducer<Text IntWritable,Text,IntWritable>{ 21 public void reduce(Text key,Iterator<IntWritable> values,OutputCollector<Text,IntWritable> output,Reporter reporter) throws IOException{ 22 //初始word个数设置 23 int sum = 0; 24 while(values,hasNext()){ 25 //单词个数相加 26 sum += value.next().get(); 27 } 28 output.collect(key,new IntWritbale(sum)); 29 } 30 } HBASE安装配置与hbase代码框架由于我使用的是外置的zookeeper，所以这里HBASE_MANAGES_ZK设置为，设置参数: export JAVA_HOME=/usr/local/yangsy/jdk1.7.0_55 export HBASE_CLASSPATH=/usr/local/hbase-1.0.2/conf export HBASE_MANAGES_ZK=false hbase-site.xml <configuration> //设置将数据写入hdfs的目录 <property> <name>hbase.rootdir</name> <value>hdfs://master:9000/usr/local/hadoop-2.6.0/hbaseData</value> </property> //设置hbase的模式为集群模式<property> <name>hbase.cluster.distributed</name> <value>true</value></property> //设置hbase的master端口地址 <property> <name>hbase.master</name> <value>hdfs://master:60000</value></property> //HBase Master Web借鉴绑定的默认端口，默认为0.0.0.0 <property> <name>hbase.master.info.port</name> <value>60010</value></property> //设置zookeeper的连接地址（必须为基数个） <property> <name>hbase.zookeeper.property.clientPort</name> <value>2183</value> </property> //zookeeper的节点 <property> <name>hbase.zookeeper.quorum</name> <value>master,slave1,slave2</value> </property> //zookeeper数据地址 <property> <name>hbase.zookeeper.property.dataDir</name> <value>/usr/local/zookeeper-3.4.6/data</value></property> //zookeeper连接超时时间 <property> <name>zookeeper.session.timeout</name> <value>60000</value> </property> </configuration> 这里要注意的是，如果选择外置的zookeeper集群，则需要将zookeeper的zoo.cfg拷贝至HBase的conf下。在启动HBase时，将会自动加载该配置文件。 regionServers中配置regionserver节点的地址代码结构： 1 package HbaseTest; 2 3 import akka.io.Tcp; 4 import org.apache.hadoop.conf.Configuration; 5 import org.apache.hadoop.hbase.*; 6 import org.apache.hadoop.hbase.client.*; 7 8 import java.util.ArrayList; 9 import java.util.List; 10 11 /** 12 * Created by root on 5/30/16. 13 */ 14 public class HbaseTest { 15 private Configuration conf; 16 public void init(){ 17 conf = HBaseConfiguration.create(); 18 } 19 20 public void createTable(){ 21 Connection conn = null; 22 try{ 23 conn = ConnectionFactory.createConnection(conf); 24 HBaseAdmin hadmin = (HBaseAdmin)conn.getAdmin(); 25 HTableDescriptor desc = new HTableDescriptor("TableName".valueOf("yangsy")); 26 27 desc.addFamily(new HColumnDescriptor("f1")); 28 if(hadmin.tableExists("yangsy")){ 29 System.out.println("table is exists!"); 30 System.exit(0); 31 }else{ 32 hadmin.createTable(desc); 33 System.out.println("create table success"); 34 } 35 }catch (Exception e){ 36 e.printStackTrace(); 37 }finally { 38 { 39 if(null != conn){ 40 try{ 41 conn.close(); 42 }catch(Exception e){ 43 e.printStackTrace(); 44 } 45 } 46 } 47 } 48 } 49 50 public void query(){ 51 Connection conn = null; 52 HTable table = null; 53 ResultScanner scan = null; 54 try{ 55 conn = ConnectionFactory.createConnection(conf); 56 table = (HTable)conn.getTable(TableName.valueOf("yangsy")); 57 58 scan = table.getScanner(new Scan()); 59 60 for(Result rs : scan){ 61 System.out.println("rowkey:" + new String(rs.getRow())); 62 63 for(Cell cell : rs.rawCells()){ 64 System.out.println("column:" + new String(CellUtil.cloneFamily(cell))); 65 66 System.out.println("columnQualifier:"+new String(CellUtil.cloneQualifier(cell))); 67 68 System.out.println("columnValue:" + new String(CellUtil.cloneValue(cell))); 69 70 System.out.println("----------------------------"); 71 } 72 } 73 }catch(Exception e){ 74 e.printStackTrace(); 75 }finally{ 76 try { 77 table.close(); 78 if(null != conn) { 79 conn.close(); 80 } 81 }catch (Exception e){ 82 e.printStackTrace(); 83 } 84 } 85 } 86 87 public void queryByRowKey(){ 88 Connection conn = null; 89 ResultScanner scann = null; 90 HTable table = null; 91 try { 92 conn = ConnectionFactory.createConnection(conf); 93 table = (HTable)conn.getTable(TableName.valueOf("yangsy")); 94 95 Result rs = table.get(new Get("1445320222118".getBytes())); 96 System.out.println("yangsy the value of rokey:1445320222118"); 97 for(Cell cell : rs.rawCells()){ 98 System.out.println("family" + new String(CellUtil.cloneFamily(cell))); 99 System.out.println("value:"+new String(CellUtil.cloneValue(cell))); 100 } 101 }catch (Exception e){ 102 e.printStackTrace(); 103 }finally{ 104 if(null != table){ 105 try{ 106 table.close(); 107 }catch (Exception e){ 108 e.printStackTrace(); 109 } 110 } 111 } 112 } 113 114 public void insertData(){ 115 Connection conn = null; 116 HTable hTable = null; 117 try{ 118 conn = ConnectionFactory.createConnection(conf); 119 hTable = (HTable)conn.getTable(TableName.valueOf("yangsy")); 120 121 Put put1 = new Put(String.valueOf("1445320222118").getBytes()); 122 123 put1.addColumn("f1".getBytes(),"Column_1".getBytes(),"123".getBytes()); 124 put1.addColumn("f1".getBytes(),"Column_2".getBytes(),"456".getBytes()); 125 put1.addColumn("f1".getBytes(),"Column_3".getBytes(),"789".getBytes()); 126 127 Put put2 = new Put(String.valueOf("1445320222119").getBytes()); 128 129 put2.addColumn("f1".getBytes(),"Column_1".getBytes(),"321".getBytes()); 130 put2.addColumn("f1".getBytes(),"Column_2".getBytes(),"654".getBytes()); 131 put2.addColumn("f1".getBytes(),"Column_3".getBytes(),"987".getBytes()); 132 133 List<Put> puts = new ArrayList<Put>(); 134 puts.add(put1); 135 puts.add(put2); 136 hTable.put(puts); 137 }catch(Exception e){ 138 e.printStackTrace(); 139 }finally{ 140 try { 141 if (null != hTable) { 142 hTable.close(); 143 } 144 }catch(Exception e){ 145 e.printStackTrace(); 146 } 147 } 148 } 149 150 public static void main(String args[]){ 151 HbaseTest test = new HbaseTest(); 152 test.init(); 153 test.createTable(); 154 test.insertData(); 155 test.query(); 156 } 157 158 159 } Storm安装配置与代码框架拓扑构造：编写topology实体类，在构造方法中加入配置参数，序列化等。通过CommandlLine获取启动时的workers与calc数量，最终调用StormSubmitter的submitTopologyWithProgressBar,传入topo的名称，配置项，以及TopologyBuilder实例。数据接收Spout： Storm从kafka中获取数据,创建于BasicTopology，其中配置参数： kafka.brokerZkStr Kafka使用的zookeeper服务器地址 kafka.brokerZkPath 保存offset的zookeeper服务器地址 kafka.offset.zkPort 保存offset的zookeeper端口默认2181 kafka.offset.zkRoot 保存offset的zookeeper路径 /kafka-offset stateUpdateIntervalMs 把offset信息写入zookeeper的间隔时间 30000 spout、bolt初始化时，构建对象stormBeanFactory,其后使用getBean方法从BeanFactory中获取对象 Bolt数据处理：自定义bolt继承自extendsBaseRichBolt，实现它的prepare、declareOutputFileds方法。在prepare方法中，获取StormBeanFactory的配置，加载业务实体类。 Storm配置参数： dev.zookeeper.path : '/tmp/dev-storm-zookeeper' 以dev.zookeeper.path配置的值作为本地目录,以storm.zookeeper.port配置的值作为端口,启动一个新的zookeeper服务drpc.childopts: '-Xms768m' drpc.invocations.port 3773drpc.port : 3772drpc.queue.size : 128drpc.request.timeout.secs : 600drpc.worker.threads : 64java.library.path : ''logviewer.appender.name : 'A1'logviewer.childopts : '-Xms128m'logviewr.port : 8000metrics.reporter.register : 'org.apache.hadoop.metrics2.sink.storm.StormTimelineMetricsReporter'nimbus.childopts : '-Xmx1024m -javaagent:/usr/hdp/current/storm-nimbus/contrib/storm-jmxetric/lib/jmxetric-1.0.4.jar=host=localhost,port=8649,wireformat31x-true...'nimbus.cleanup.inbox.freq.secs : 600nimbus.file.copy.exiration.secs : 600 storm.yaml nimbus.host nimbus的配置地址 nimbus.inbox.jar.expiration.secs 主要负责清理nimbus的inbox文件夹最后一次修改时间,默认3600秒 nimbus.monitor.freq.secs : 120nimbus.reassign : true 当发现task失败时nimbus是否重新分配执行。默认为真，不建议修改nimbus.supervisor.timeout.secs : 60nimbus.task.launch.secs : 120nimbus.task.timeout.secs : 30 心跳超时时间，超时后nimbus会认为task死掉并重分配给另一个地址nimbus.thrift.max_buffer_size : 1048576nimbus.thrift.port : 6627nimbus.topology.validator : 'backtype.storm.nimbus.DefaultTopologyValidator'storm.cluster.metrics.consumer.register : [{"class" : "org.apache.hadoop.metrics2.sink.storm.Strorm.StormTimeLineMetricsReporter"}]storm.cluster.mode : 'distributed'storm.local.dir : '/storage/disk1/hadoop/storm'storm.local.mode.zmq : falsestorm.log.dir : '/var/log/storm'storm.messaging.netty.buffer_size : 5242880 为每次批量发送的Tuple 序列化之后的Task Message 消息的大小storm.messaging.netty.client_worker_threads : 10 指定netty服务器工作线程数量storm.messaging.netty.max_retries : 60 指定最大重试次数storm.messaging.netty.max_wait_ms : 2000 指定最大等待时间（毫秒）storm.messaging.netty.min_wait_ms : 100指定最小等待时间（毫秒）storm.messaging.netty.server_worker_threads : 10指定netty服务器工作线程数量storm.messaging.transport : 'backtype.storm.messaging.netty.Context'指定传输协议storm.thrift.transport : 'backtype.storm.security.auth.SimpleTransportPlugin'storm.zookeeper.connection.timeout : 15000storm.zookeeper.port : 2181storm.zookeeper.retry.interval : 1000storm.zookeeper.retry.intervalceiling.millis : 30000storm.zookeeper.retry.times : 5storm.zookeeper.root : '/storm' ZooKeeper中Storm的根目录位置storm.zookeeper.servers : ['',''.....] zookeeper服务器列表storm.zookeeper.session.timeout : 20000 客户端连接ZooKeeper超时时间supervisor.childopts : 在storm-deploy项目中使用,用来配置supervisor守护进程的jvm选项supervisor.heartbeat.frequency.secs : 5 supervisor心跳发送频率(多久发送一次)supervisor.monitor.frequency.secs : 3 supervisor检查worker心跳的频率supervisor.slots.ports : [6700,6701,....] supervisor上能够运行workers的端口列表.每个worker占用一个端口,且每个端口只运行一个worker.通过这项配置可以调整每台机器上运行的worker数.(调整slot数/每机)supervisor.worker.start.timeout.secs : 120supervisor.worker.timeout.secs : 30 supervisor中的worker心跳超时时间,一旦超时supervisor会尝试重启worker进程.task.heartbeat.frequency.secs : 3 task汇报状态心跳时间间隔task.refresh.poll.secs : 10 ask与其他tasks之间链接同步的频率.(如果task被重分配,其他tasks向它发送消息需要刷新连接).一般来讲，重分配发生时其他tasks会理解得到通知。该配置仅仅为了防止未通知的情况。topology.acker.executors : nulltopology.builtin.metrics.bucket.size.secs : 60topology.debug : falsetopology.disruptor.wait.strategy : 'com.lmax.disruptor.BlockingWaitStrategy'topology.enable.message.timeouts : truetopology.error.throttle.interval.secs : 10topology.executor.receive.buffer.size : 1024topology.executor.send.buffer.size : 1024topology.fall.back.on.java.serialization : truetopology.kryo.factory : 'backtype.storm.serialization.DefaultKryoFactory'topology.max.error.report.per.interval : 5topology.max.spout.pending : null 一个spout task中处于pending状态的最大的tuples数量.该配置应用于单个task,而不是整个spouts或topology.topology.max.task.parallelism : null 在一个topology中能够允许的最大组件并行度.该项配置主要用在本地模式中测试线程数限制.topology.message.timeout.secs : 30 topology中spout发送消息的最大处理超时时间.如果一条消息在该时间窗口内未被成功ack,Storm会告知spout这条消息失败。而部分spout实现了失败消息重播功能。topology.metrics.aggregate.metric.evict.secs : 5topology.metrics.aggregate.per.worker : truetopology.metrics.consumer.register : topology.metrics.expand.map.type : truetopology.metrics.metric.name.separator : ','topology.optimize ： truetopology.skip.missing.kryo.registrations : false Storm是否应该跳过它不能识别的kryo序列化方案.如果设置为否task可能会装载失败或者在运行时抛出错误.topology.sleep.spout.wait.strategy.time.ms : 1topology.spoout.wait.strategy : 'backtype.storm.spout.SleeSpoutWaitStrategy'topology.state.synchronization.timeout.secs : 60topology.stats.sample.rate : 0.05topology.tick.tuple.freq.secs : nulltopology.transfer.buffer.size : 1024topology.trident.batch.emit.interval.millis : 500topology.tuple.serializer : 'backtype.storm.serialization.types.ListDelegateSerializer'topology.worker.childopts : nulltopology.worker.shared.thread.pool.size : 4topology.workers : 40 执行该topology集群中应当启动的进程数量.每个进程内部将以线程方式执行一定数目的tasks.topology的组件结合该参数和并行度提示来优化性能transactional.zookeeper.port : nulltransactional.zookeeper.root : '/transactional'transactional.zookeeper.servers : nullui.childopts : '-Xmx2048m'ui.filter : nullui.port : 8744 Storm UI的服务端口worker.childopts :worker.heartbeet.frequency.secs : 1zmq.hwm : 0zmq.linger.millis : 5000 当连接关闭时,链接尝试重新发送消息到目标主机的持续时长.这是一个不常用的高级选项,基本上可以忽略.zmq.threads : 1 每个worker进程内zeromq通讯用到的线程数 storm代码框架总结：基类topology,BasicTopology.java 1 import java.io.UnsupportedEncodingException; 2 import java.math.BigDecimal; 3 import java.util.Date; 4 import java.util.HashMap; 5 import java.util.List; 6 import java.util.Map; 7 8 import org.apache.commons.cli.CommandLine; 9 import org.apache.commons.cli.CommandLineParser; 10 import org.apache.commons.cli.DefaultParser; 11 import org.apache.commons.cli.HelpFormatter; 12 import org.apache.commons.cli.Options; 13 import org.apache.commons.lang3.StringUtils; 14 import org.apache.storm.guava.base.Preconditions; 15 import org.edm.storm.topo.util.DelayKafkaSpout; 16 import org.edm.storm.topo.util.StormBeanFactory; 17 import org.joda.time.DateTime; 18 19 import storm.kafka.BrokerHosts; 20 import storm.kafka.KafkaSpout; 21 import storm.kafka.SpoutConfig; 22 import storm.kafka.ZkHosts; 23 import backtype.storm.Config; 24 import backtype.storm.LocalCluster; 25 import backtype.storm.StormSubmitter; 26 import backtype.storm.topology.TopologyBuilder; 27 import backtype.storm.tuple.Fields; 28 29 public abstract class BasicTopology { 30 31 public static final String HASH_TAG = "hashTag"; 32 33 public static final Fields HASH_FIELDS = new Fields(HASH_TAG); 34 35 protected Options options = new Options(); 36 37 protected StormBeanFactory stormBeanFactory; 38 39 protected Config config = new Config(); 40 41 protected String configFile; 42 43 public BasicTopology(){ 44 config.setFallBackOnJavaSerialization(false); 45 46 config.setSkipMissingKryoRegistrations(false); 47 config.registerSerialization(Date.class); 48 config.registerSerialization(BigDecimal.class); 49 config.registerSerialization(HashMap.class); 50 config.registerSerialization(Map.class); 51 52 options.addOption("name", true, "拓扑运行时名称"); 53 options.addOption("conf", false, "配置文件路径"); 54 options.addOption("workers", true, "虚拟机数量"); 55 } 56 57 protected void setupConfig(CommandLine cmd) throws UnsupportedEncodingException{ 58 //配置文件名称 59 String confLocation = cmd.getOptionValue("conf",getConfigName()); 60 //创建stormBeanFactory 61 stormBeanFactory = new StormBeanFactory(confLocation); 62 Map<String,Object> stormConfig = stormBeanFactory.getBean("stormConfig",Map.class); 63 Preconditions.checkNotNull(stormConfig); 64 config.putAll(stormConfig); 65 config.put(StormBeanFactory.SPRING_BEAN_FACTORY_XML, stormBeanFactory.getXml()); 66 //先默认加载，然后再加载命令行 67 String numWorkers = cmd.getOptionValue("workers"); 68 if(numWorkers != null){ 69 config.setNumWorkers(Integer.parseInt(numWorkers)); 70 }else{ 71 config.setNumWorkers(getNumWorkers()); 72 } 73 config.put(Config.TOPOLOGY_MESSAGE_TIMEOUT_SECS, 180); 74 config.put(Config.TOPOLOGY_MAX_SPOUT_PENDING, 2000); 75 config.put(Config.TOPOLOGY_EXECUTOR_RECEIVE_BUFFER_SIZE, 16384); 76 config.put(Config.TOPOLOGY_EXECUTOR_SEND_BUFFER_SIZE, 16384); 77 config.put(Config.TOPOLOGY_ACKER_EXECUTORS, config.get(Config.TOPOLOGY_WORKERS)); 78 } 79 80 @SuppressWarnings("unchecked") 81 protected SpoutConfig getSpoutConfig(String topic){ 82 String brokerZkStr = (String)config.get("kafka.brokerZkStr"); 83 String brokerZkPath = (String)config.get("kafka.brokerZkPath"); 84 85 List<String> zkServers = (List<String>)config.get("kafka.offset.zkServers"); 86 Integer zkPort = Integer.parseInt(String.valueOf(config.get("kafka.offset.zkPort"))); 87 String zkRoot = (String)config.get("kafka.offset.zkRoot"); 88 String id = StringUtils.join(getTopoName(),"-",topic); 89 BrokerHosts kafkaBrokerZk = new ZkHosts(brokerZkStr, brokerZkPath); 90 SpoutConfig spoutConfig = new SpoutConfig(kafkaBrokerZk, topic, zkRoot, id); 91 spoutConfig.zkServers = zkServers; 92 spoutConfig.zkPort = zkPort; 93 spoutConfig.zkRoot = zkRoot; 94 spoutConfig.stateUpdateIntervalMs = 30000; 95 return spoutConfig; 96 } 97 98 //创建kafkaspout 99 public KafkaSpout getKafkaSpout(String topic){ 100 SpoutConfig spoutConfig = getSpoutConfig(topic); 101 return new DelayKafkaSpout(spoutConfig); 102 } 103 104 105 /** 106 * 拓扑可部署多次，但从kafka获取数据，做唯一次过滤等用的 107 * 108 * @return 109 */ 110 public abstract String getTopoName(); 111 112 public abstract String getConfigName(); 113 114 public abstract int getNumWorkers(); 115 116 public void registerKryo(Config config){ 117 118 } 119 120 public abstract void addOptions(Options options); 121 122 public abstract void setupOptionValue(CommandLine cmd); 123 124 public abstract void createTopology(TopologyBuilder builder); 125 126 public void runLocat(String[] args) throws Exception{ 127 CommandLineParser parser = new DefaultParser(); 128 CommandLine cmd = parser.parse(options, args); 129 HelpFormatter formatter = new HelpFormatter(); 130 formatter.printHelp("topology", options); 131 setupConfig(cmd); 132 133 config.setDebug(true); 134 config.setNumWorkers(1); 135 TopologyBuilder builder = new TopologyBuilder(); 136 createTopology(builder); 137 LocalCluster cluster = new LocalCluster(); 138 String topoName = cmd.getOptionValue("name", 139 StringUtils.join(getTopoName(), "-", new DateTime().toString("yyyyMMdd-HHmmss"))); 140 cluster.submitTopology(topoName,config,builder.createTopology()); 141 142 } 143 144 public void run(String args[]) throws Exception{ 145 CommandLineParser parser = new DefaultParser(); 146 CommandLine cmd = parser.parse(options, args); 147 HelpFormatter formatter = new HelpFormatter(); 148 formatter.printHelp("topology", options); 149 setupConfig(cmd); 150 setupOptionValue(cmd); 151 152 TopologyBuilder builder = new TopologyBuilder(); 153 createTopology(builder); 154 String topoName = cmd.getOptionValue("name",StringUtils.join(getTopoName(),new DateTime().toString("yyyyMMdd-HHmmss"))); 155 StormSubmitter.submitTopologyWithProgressBar(topoName, config, builder.createTopology()); 156 } 157 } 用于实现数据流spout,bolt的业务实现Topology: 1 import org.apache.commons.cli.CommandLine; 2 import org.apache.commons.cli.Options; 3 4 import storm.kafka.KafkaSpout; 5 6 import backtype.storm.topology.TopologyBuilder; 7 8 import com.practice.impl.BasicTopology; 9 10 public class LbsCalcTopology extends BasicTopology{ 11 12 private int spoutParallelism = 1; 13 14 private int onceParallelism = 1; 15 16 private int calculateParallelism = 1; 17 18 19 @Override 20 public void addOptions(Options options) { 21 options.addOption("spout",true,"spoutParallelism"); 22 options.addOption("once",true,"onceParallelism"); 23 options.addOption("calc",true,"calculateParallelism"); 24 } 25 26 @Override 27 public void setupOptionValue(CommandLine cmd) { 28 spoutParallelism = Integer.parseInt(cmd.getOptionValue("spout","1")); 29 onceParallelism = Integer.parseInt(cmd.getOptionValue("once","1")); 30 calculateParallelism = Integer.parseInt(cmd.getOptionValue("calc","1")); 31 } 32 33 @Override 34 public void createTopology(TopologyBuilder builder) { 35 KafkaSpout kafkaSpout = getKafkaSpout("lbs"); 36 LbsOnceBolt exactlyOnceBolt = new LbsOnceBolt(getTopoName(),"lbs","lbs"); 37 LbsCalcBolt calculateBolt = new LbsCalcBolt(); 38 39 builder.setSpout("kafkaSpout", kafkaSpout,spoutParallelism); 40 builder.setBolt("onceParallelism", exactlyOnceBolt,onceParallelism).shuffleGrouping("kafkaSpout"); 41 builder.setBolt("calculateBolt", calculateBolt, calculateParallelism).fieldsGrouping("onceParallelism", BasicTopology.HASH_FIELDS); 42 } 43 44 @Override 45 public String getTopoName() { 46 return "lbs"; 47 } 48 49 @Override 50 public String getConfigName() { 51 return "lbs-topology.xml"; 52 } 53 54 @Override 55 public int getNumWorkers() { 56 return 3; 57 } 58 59 public static void main(String args[]) throws Exception{ 60 LbsCalcTopology topo = new LbsCalcTopology(); 61 topo.run(args); 62 } 63 } 具体业务时间bolt: 1 import java.util.Map; 2 3 import backtype.storm.task.OutputCollector; 4 import backtype.storm.task.TopologyContext; 5 import backtype.storm.topology.OutputFieldsDeclarer; 6 import backtype.storm.topology.base.BaseRichBolt; 7 import backtype.storm.tuple.Tuple; 8 9 public class LbsCalcBolt extends BaseRichBolt{ 10 11 @Override 12 public void execute(Tuple input) { 13 try{ 14 String msg = input.getString(0); 15 if(msg != null){ 16 System.out.println(msg); 17 } 18 }catch(Exception e){ 19 e.printStackTrace(); 20 } 21 } 22 23 @Override 24 public void prepare(Map arg0, TopologyContext arg1, OutputCollector arg2) { 25 // TODO Auto-generated method stub 26 27 } 28 29 @Override 30 public void declareOutputFields(OutputFieldsDeclarer arg0) { 31 // TODO Auto-generated method stub 32 33 } 34 35 } Kafka安装配置与代码框架 1、主要配置参数说明-- 日志数据存储目录log.dirs = /storage/disk17/kafka-logs-- Kafka server端口port = 6667-- 强制切分日志文件的间隔时间（切分的文件大小由log.segment.bytes决定，默认1073741824 bytes）log.roll.hours = 168-- 日志文件保留时间log.retention.hours = 168-- 每次flush到磁盘的最大消息数量，数量太大会让写磁盘时间过长(IO阻塞)，导致客户端发生延迟log.flush.interval.messages=10000-- 每次flush消息的间隔时间log.flush.scheduler.interval.ms=3000-- zookeeper 连接超时时间zookeeper.connection.timeout.ms = 20000-- zookeeper 集群的节点地址，多个以，号分隔zookeeper.connect=127.0.0.1:2181-- zooKeeper集群中leader和follower之间的同步时间zookeeper.sync.time.ms=2000-- 是否允许自动创建主题auto.create.topics.enable=true-- 默认复制因子数量default.replication.factor=1-- 默认分区数量num.partitions=12、消息以及日志数据的存储策略kafka和JMS（Java Message Service）实现(activeMQ)不同的是：即使消息被消费，消息仍然不会被立即删除，日志文件将会根据broker中的配置要求，保留一定的时间之后删除，比如log.retention.hours=168，那么七天后，文件会被清除，无论其中的消息是否被消费。kafka通过这种简单的手段，来释放磁盘空间，以及减少消息消费之后对文件内容改动的磁盘IO开销。对于consumer而言，它需要保存消费消息的offset（如果不指定则存储在默认的zookeeper目录kafak-broker），对于offset的保存和使用，由consumer来控制。当consumer正常消费消息时，offset将会"线性"的向前驱动，即消息将依次顺序被消费。事实上consumer可以使用任意顺序消费消息，它只需要将offset重置为任意值。kafka集群几乎不需要维护任何consumer和producer状态信息，这些信息由zookeeper保存。因此producer和consumer的客户端实现非常轻量级，它们可以随意离开，而不会对集群造成额外的影响。3、常用操作命令3.1、创建消息主题(kafka topic)./kafka-topics.sh --zookeeper 127.0.0.1:2181 --topic topicName --partitions 2 --replication-factor 3 --create--zookeeper zookeeper 服务端地址--topic 消息主题名称--partitions 分区数量（如果不指定数量则由Kafka的配置决定）--replication-factor 复制因子数量（副本数量，如果不指定数量则由Kafka的配置决定）--create 创建主题3.2、删除消息主题* 慎用，这条命令只是删除zookeeper中主题的元数据，日志文件并不会删除，不建议直接删除日志文件。如需删除，安全的措施是停止kafka集群服务，然后执行这条命令再删除日志文件，最后恢复服务，恢复服务后执行--describe命令（3.3）检查主题是否已经移除！./kafka-run-class.sh kafka.admin.DeleteTopicCommand --zookeeper 127.0.0.1:2181 --topic topicName3.3、查看消息主题./kafka-topics.sh --zookeeper 127.0.0.1:2181 --topic topicName --describe--zookeeper zookeeper 服务端地址--topic 消息主题名称----describe 主题信息命令将输出如下信息，如topicName主题有2个分区，复制因子为3，以及主题所在的leader。Topic:topicName PartitionCount:2 ReplicationFactor:3 Configs: Topic: topicName Partition: 0 Leader: 2 Replicas: 2,1,0 Isr: 2,1,0 Topic: topicName Partition: 1 Leader: 0 Replicas: 0,2,1 Isr: 0,2,13.4、其他命令-- 列出所有的主题./kafka-topics.sh --zookeeper 127.0.0.1:2181 --list-- 修改主题分区数量./kafka-topics.sh --zookeeper 127.0.0.1:2181 --topic topicName --partitions 4 --alter Redis安装配置与代码框架 Jettry配置与代码框架 Jetty服务一共启动8个线程进行数据的接入。存储于bLOCKINGqUEUE中，进行消费，启启动多个线程的作用在于并发消费接入的报文数据。同时，同一事件启动多个服务，通过nginx进行负载均衡。一、Jetty服务的启动 1、创建ApplicationContext,通过AbstractApplicationContext创建。AbstractApplicationContext applicationContext = new FileSystemXmlApplicationContext(configXmlFile); 2、创建PlatformMBeanServerMBeanServer mbs = java.lang.management.ManagementFactory.getPlatformMBeanServer(); 3、注册ApplicationServer ObjectName mbeanName = getApplicationObjectName(); ApplicationServer applicationServer = new ApplicationServer(); .... mbs.registerMBean(applicationServer,mbeanNamer); 二、Jettry服务的停止...... HIVE安装配置与代码框架 Rstudio与Spark安装配置与代码框架 Nginx配置 user www-data; #运行用户worker_processes 1; #启动进程,通常设置成和cpu的数量相等error_log /var/log/nginx/error.log; #全局错误日志及PID文件pid /var/run/nginx.pid;#PID文件 #工作模式及连接数上限events { use epoll; #epoll是多路复用IO(I/O Multiplexing)中的一种方式,但是仅用于linux2.6以上内核,可以大大提高nginx的性能 worker_connections 1024;#单个后台worker process进程的最大并发链接数 # multi_accept on; } #设定http服务器，利用它的反向代理功能提供负载均衡支持http { #设定mime类型,类型由mime.type文件定义include /etc/nginx/mime.types;default_type application/octet-stream;#设定日志格式access_log /var/log/nginx/access.log; #sendfile 指令指定 nginx 是否调用 sendfile 函数（zero copy 方式）来输出文件，对于普通应用， #必须设为 on,如果用来进行下载等应用磁盘IO重负载应用，可设置为 off，以平衡磁盘与网络I/O处理速度，降低系统的uptime.sendfile on; #tcp_nopush on; #连接超时时间 #keepalive_timeout 0; keepalive_timeout 65;tcp_nodelay on; #开启gzip压缩gzip on;gzip_disable "MSIE [1-6]\.(?!.*SV1)"; #设定请求缓冲client_header_buffer_size 1k;large_client_header_buffers 4 4k; include /etc/nginx/conf.d/*.conf;include /etc/nginx/sites-enabled/*; #设定负载均衡的服务器列表 upstream mysvr { #weigth参数表示权值，权值越高被分配到的几率越大 #本机上的Squid开启3128端口 server 192.168.8.1:3128 weight=5; server 192.168.8.2:80 weight=1; server 192.168.8.3:80 weight=6; } server {#侦听80端口 listen 80;#定义使用www.xx.com访问 server_name www.xx.com;(虚拟主机ip) #设定本虚拟主机的访问日志 access_log logs/www.xx.com.access.log main; #默认请求 location / { root /root; #定义服务器的默认网站根目录位置 index index.php index.html index.htm; #定义首页索引文件的名称 fastcgi_pass www.xx.com; fastcgi_param SCRIPT_FILENAME $document_root/$fastcgi_script_name; include /etc/nginx/fastcgi_params; } # 定义错误提示页面 error_page 500 502 503 504 /50x.html; location = /50x.html { root /root; } #静态文件，nginx自己处理 location ~ ^/(images|javascript|js|css|flash|media|static)/ { root /var/www/virtual/htdocs; #过期30天，静态文件不怎么更新，过期可以设大一点，如果频繁更新，则可以设置得小一点。 expires 30d; }#PHP 脚本请求全部转发到 FastCGI处理. 使用FastCGI默认配置. location ~ \.php$ { root /root; fastcgi_pass 127.0.0.1:9000; fastcgi_index index.php; fastcgi_param SCRIPT_FILENAME /home/www/www$fastcgi_script_name; include fastcgi_params; }#设定查看Nginx状态的地址 location /NginxStatus { stub_status on; access_log on; auth_basic "NginxStatus"; auth_basic_user_file conf/htpasswd; }#禁止访问 .htxxx 文件 location ~ /\.ht { deny all; } }} Sentry配置 Hue配置（3.11版本） hue安装rpm -ivh hue-* --force --nodepsrpm -ivh sentry-* --force --nodeps hue 启动/usr/lib/hue/build/env/bin/hue runserver ip:port > /var/log/hue/hue-start.out 2> /var/log/hue/hue-error.out & spark livy 集成hue sqlited is locked desktopdefault_hdfs_superuserhadoopHDFS管理用户desktophttp_host10.10.4.125Hue Web Server所在主机/IPdesktophttp_port8000Hue Web Server服务端口desktopserver_userhadoop运行Hue Web Server的进程用户desktopserver_grouphadoop运行Hue Web Server的进程用户组desktopdefault_useryanjunHue管理员 1. 新建hue用户#usradd hue将包放到/home/hue/底下(可以自己选择位置)#rpm -ivh hue-* --force --nodeps安装完成之后，hue的目录在/usr/lib/hue,配置文件目录在/etc/hue/conf/hue.ini2. 配置hue(/etc/hue/conf/hue.ini)[beeswax]# Host where HiveServer2 is running.# If Kerberos security is enabled, use fully-qualified domain name (FQDN).hive_server_host=172.19.189.50(hiveserver2的地址)# Port where HiveServer2 Thrift server runs on.hive_server_port=10010(hiveserver2端口)# Hive configuration directory, where hive-site.xml is locatedhive_conf_dir=/etc/conf(hive配置文件路径)# Timeout in seconds for thrift calls to Hive serviceserver_conn_timeout=120(连接hive超时时间)# Choose whether to use the old GetLog() thrift call from before Hive 0.14 to retrieve the logs.# If false, use the FetchResults() thrift call from Hive 1.0 or more instead.## use_get_log_api=false# Limit the number of partitions that can be listed.list_partitions_limit=10000(不限制时查询界面上list的partition数据)# The maximum number of partitions that will be included in the SELECT * LIMIT sample query for partitioned tables.query_partitions_limit=10(查询语句中最多查询10个partition)# A limit to the number of cells (rows * columns) that can be downloaded from a query# (e.g. - 10K rows * 1K columns = 10M cells.)# A value of -1 means there will be no limit.download_cell_limit=10000000(download最大量)# Hue will try to close the Hive query when the user leaves the editor page.# This will free all the query resources in HiveServer2, but also make its results inaccessible.close_queries=true(关闭界面时直接断开该用户与hiveserver2的连接)# Thrift version to use when communicating with HiveServer2.# New column format is from version 7.thrift_version=7(默认值，不建议改会报错)[[yarn_clusters]][[[default]]]# Enter the host on which you are running the ResourceManagerresourcemanager_host= (RM地址)# The port where the ResourceManager IPC listens onresourcemanager_port=8032(RM端口)# Whether to submit jobs to this clustersubmit_to=True# Resource Manager logical name (required for HA)logical_name=ActiveResourceManager(HA，给activeRM命名)# Change this if your YARN cluster is Kerberos-secured## security_enabled=false# URL of the ResourceManager APIresourcemanager_api_url=http://172.19.xxx.xx:8088(RM URL)# URL of the ProxyServer API## proxy_api_url=http://localhost:8088# URL of the HistoryServer APIhistory_server_api_url=http://172.19.xx.xx:19888# URL of the Spark History Server#spark_history_server_url=http://172.30.xx.xx:18088# In secure mode (HTTPS), if SSL certificates from YARN Rest APIs# have to be verified against certificate authority## ssl_cert_ca_verify=True# HA support by specifying multiple clusters.# Redefine different properties there.# e.g. [[[ha]]]# Resource Manager logical name (required for HA)logical_name=StandbyResourceManager(RM的HA从节点name)# Un-comment to enablesubmit_to=True# URL of the ResourceManager APIresourcemanager_api_url=http://172.19.189.50:8088(RM从节点地址)[hadoop]# Configuration for HDFS NameNode# ------------------------------------------------------------------------[[hdfs_clusters]]# HA support by using HttpFs [[[default]]]# Enter the filesystem urifs_defaultfs=hdfs://hdp(HDFS的filesystem名字) # NameNode logical name.logical_name=MasterNamenode(NN name) # Use WebHdfs/HttpFs as the communication mechanism. # Domain should be the NameNode or HttpFs host. # Default port is 14000 for HttpFs.webhdfs_url=http://172.19.189.50:50070/webhdfs/v1(hue的获取hdfs的nn HA是通过WebHDFS来切换的，这个地址是启动Webhdfs的地址) # Change this if your HDFS cluster is Kerberos-secured ## security_enabled=false # In secure mode (HTTPS), if SSL certificates from YARN Rest APIs # have to be verified against certificate authority ## ssl_cert_ca_verify=True # Directory of the Hadoop configurationhadoop_conf_dir=/etc/hadoop/conf(hadoop配置文件路径)[desktop]# Set this to a random string, the longer the better.# This is used for secure hashing in the session store.## secret_key=# Execute this script to produce the Django secret key. This will be used when# 'secret_key' is not set.## secret_key_script=# Webserver listens on this address and porthttp_host=0.0.0.0http_port=8888# Time zone nametime_zone=Asia/Shanghai# Enable or disable Django debug mode.#django_debug_mode=false# Enable or disable database debug mode.#database_logging=false# Whether to send debug messages from JavaScript to the server logs.#send_dbug_messages=true# Enable or disable backtrace for server errorhttp_500_debug_mode=true# Enable or disable memory profiling.## memory_profiler=false# Server email for internal error messages## django_server_email='hue@localhost.localdomain'# Email backend## django_email_backend=django.core.mail.backends.smtp.EmailBackend# Webserver runs as this userserver_user=hueserver_group=hadoop(hue界面登录用户)# This should be the Hue admin and proxy userdefault_user=hue(hue管理员用户)# This should be the hadoop cluster admindefault_hdfs_superuser=hue(hue在hdfs上的管理员用户)[[database]]#engine=sqlite3#name=/var/lib/hue/desktop.db# Database engine is typically one of:# postgresql_psycopg2, mysql, sqlite3 or oracle.# Note that for sqlite3, 'name', below is a path to the filename. For other backends, it is the database name# Note for Oracle, options={"threaded":true} must be set in order to avoid crashes.# Note for Oracle, you can use the Oracle Service Name by setting "host=" and "port=" and then "name=<host>:<port>/<service_name>".# Note for MariaDB use the 'mysql' engine.engine=mysqlhost=172.30.115.60port=3306user=huepassword=huename=hue(hue的元数据存储位置)# Execute this script to produce the database password. This will be used when 'password' is not set.## password_script=/path/script## name=desktop/desktop.db## options={}[librdbms]# The RDBMS app can have any number of databases configured in the databases# section. A database is known by its section name# (IE sqlite, mysql, psql, and oracle in the list below).[[databases]] # sqlite configuration. ## [[[sqlite]]] # Name to show in the UI. ## nice_name=SQLite # For SQLite, name defines the path to the database. ## name=/tmp/sqlite.db # Database backend to use. ## engine=sqlite # Database options to send to the server when connecting. # https://docs.djangoproject.com/en/1.4/ref/databases/ ## options={}# mysql, oracle, or postgresql configuration.[[[mysql]]](开启mysql) # Name to show in the UI. nice_name="HUE DB"(界面显示mysql的名字) # For MySQL and PostgreSQL, name is the name of the database. # For Oracle, Name is instance of the Oracle server. For express edition # this is 'xe' by default. name=hue(连接的mysql数据库)# Database backend to use. This can be: # 1. mysql # 2. postgresql # 3. oracle engine=mysql(连接引擎) # IP or hostname of the database to connect to. host=172.30.115.60(mysql地址) # Port the database server is listening to. Defaults are: # 1. MySQL: 3306 # 2. PostgreSQL: 5432 # 3. Oracle Express Edition: 1521 port=3306(端口) # Username to authenticate with when connecting to the database. user=hue(连接数据库的用户) # Password matching the username to authenticate with when # connecting to the database. password=hue(连接数据库的密码) # Database options to send to the server when connecting. # https://docs.djangoproject.com/en/1.4/ref/databases/ ## options={}修改hue源码1. /usr/lib/hue/desktop/libs/notebook/src/notebook/connectors/hiveserver2.py添加调用query_server方法：def _get_db(self, snippet): LOG.info('log by ck get_db') if snippet['type'] == 'hive': name = 'beeswax' elif snippet['type'] == 'impala': name = 'impala' else: name = 'spark-sql' return dbms.get_by_type(self.user, 'data', query_server=get_query_server_config_for_meta(name=name))修改计算(exector)的执行方法@query_error_handlerdef execute(self, notebook, snippet): db = self._get_db(snippet) statement = self._get_current_statement(db, snippet) session = self._get_session(notebook, snippet['type']) query = self._prepare_hql_query(snippet, statement['statement'], session) try: if statement.get('statement_id') == 0: db.use(query.database) handle = db.client.query(query) except QueryServerException, ex: raise QueryError(ex.message, handle=statement) # All good server_id, server_guid = handle.get() response = { 'secret': server_id, 'guid': server_guid, 'operation_type': handle.operation_type, 'has_result_set': handle.has_result_set, 'modified_row_count': handle.modified_row_count, 'log_context': handle.log_context, } response.update(statement) return response 2. /usr/lib/hue/apps/beeswax/src/beeswax/server/dbms.py添加query执行的路径：(修改ip为spark的ip和端口)def get_query_server_config_for_meta(name='beeswax', server=None): if name == 'impala': from impala.dbms import get_query_server_config as impala_query_server_config query_server = impala_query_server_config() else: kerberos_principal = hive_site.get_hiveserver2_kerberos_principal(HIVE_SERVER_HOST.get()) query_server = { 'server_name': 'beeswax', # Aka HiveServer2 now 'server_host': '172.30.115.58',#HIVE_SERVER_HOST.get(), 'server_port': '10010',#HIVE_SERVER_PORT.get(), 'principal': kerberos_principal, 'http_url': '%(protocol)s://%(host)s:%(port)s/%(end_point)s' % { 'protocol': 'https' if hiveserver2_use_ssl() else 'http', 'host': '172.30.115.58',#HIVE_SERVER_HOST.get(), 'port': hive_site.hiveserver2_thrift_http_port(), 'end_point': hive_site.hiveserver2_thrift_http_path() }, 'transport_mode': 'http' if hive_site.hiveserver2_transport_mode() == 'HTTP' else 'socket', 'auth_username': AUTH_USERNAME.get(), 'auth_password': AUTH_PASSWORD.get() } if name == 'sparksql': # Spark SQL is almost the same as Hive from spark.conf import SQL_SERVER_HOST as SPARK_SERVER_HOST, SQL_SERVER_PORT as SPARK_SERVER_PORT query_server.update({ 'server_name': 'sparksql', 'server_host': SPARK_SERVER_HOST.get(), 'server_port': SPARK_SERVER_PORT.get() }) debug_query_server = query_server.copy() debug_query_server['auth_password_used'] = bool(debug_query_server.pop('auth_password')) LOG.info("Query Server: %s" % debug_query_server) return query_server添加query的cache lockingDBMS_CACHE = {} DBMS_CACHE_LOCK = threading.Lock() DBMS_META_CACHE = {} DBMS_META_CACHE_LOCK = threading.Lock() DBMS_DATA_CACHE = {} DBMS_DATA_CACHE_LOCK = threading.Lock() def get(user, query_server=None): global DBMS_CACHE global DBMS_CACHE_LOCK if query_server is None: query_server = get_query_server_config() DBMS_CACHE_LOCK.acquire() try: DBMS_CACHE.setdefault(user.username, {}) if query_server['server_name'] not in DBMS_CACHE[user.username]: # Avoid circular dependency from beeswax.server.hive_server2_lib import HiveServerClientCompatible if query_server['server_name'] == 'impala': from impala.dbms import ImpalaDbms from impala.server import ImpalaServerClient DBMS_CACHE[user.username][query_server['server_name']] = ImpalaDbms(HiveServerClientCompatible(ImpalaServerClient(query_server, user)), QueryHistory.SERVER_TYPE[1][0]) else: from beeswax.server.hive_server2_lib import HiveServerClient DBMS_CACHE[user.username][query_server['server_name']] = HiveServer2Dbms(HiveServerClientCompatible(HiveServerClient(query_server, user)), QueryHistory.SERVER_TYPE[1][0]) return DBMS_CACHE[user.username][query_server['server_name']] finally: DBMS_CACHE_LOCK.release() def get_by_type(user, type, query_server=None): global DBMS_META_CACHE global DBMS_META_CACHE_LOCK global DBMS_DATA_CACHE global DBMS_DATA_CACHE_LOCK if query_server is None: query_server = get_query_server_config() if type == 'meta': DBMS_META_CACHE_LOCK.acquire() try: DBMS_META_CACHE.setdefault(user.username, {}) if query_server['server_name'] not in DBMS_META_CACHE[user.username]: # Avoid circular dependency from beeswax.server.hive_server2_lib import HiveServerClientCompatible if query_server['server_name'] == 'impala': from impala.dbms import ImpalaDbms from impala.server import ImpalaServerClient DBMS_META_CACHE[user.username][query_server['server_name']] = ImpalaDbms(HiveServerClientCompatible(ImpalaServerClient(query_server, user)), QueryHistory.SERVER_TYPE[1][0]) else: from beeswax.server.hive_server2_lib import HiveServerClient DBMS_META_CACHE[user.username][query_server['server_name']] = HiveServer2Dbms(HiveServerClientCompatible(HiveServerClient(query_server, user)), QueryHistory.SERVER_TYPE[1][0]) return DBMS_META_CACHE[user.username][query_server['server_name']] finally: DBMS_META_CACHE_LOCK.release() else: DBMS_DATA_CACHE_LOCK.acquire() try: DBMS_DATA_CACHE.setdefault(user.username, {}) if query_server['server_name'] not in DBMS_DATA_CACHE[user.username]: # Avoid circular dependency from beeswax.server.hive_server2_lib import HiveServerClientCompatible if query_server['server_name'] == 'impala': from impala.dbms import ImpalaDbms from impala.server import ImpalaServerClient DBMS_DATA_CACHE[user.username][query_server['server_name']] = ImpalaDbms(HiveServerClientCompatible(ImpalaServerClient(query_server, user)), QueryHistory.SERVER_TYPE[1][0]) else: from beeswax.server.hive_server2_lib import HiveServerClient DBMS_DATA_CACHE[user.username][query_server['server_name']] = HiveServer2Dbms(HiveServerClientCompatible(HiveServerClient(query_server, user)), QueryHistory.SERVER_TYPE[1][0]) return DBMS_DATA_CACHE[user.username][query_server['server_name']] finally: DBMS_DATA_CACHE_LOCK.release()3. /usr/lib/hue/apps/filebrowser/src/filebrowser/templates/listdir.mako删除filebrower中的delete和drop< !-- ko if: $root.isS3 -->< button class ="btn fileToolbarBtn delete-link" title="${_('Delete forever')}" data-bind="enable: selectedFiles().length > 0, click: deleteSelected" > < i class ="fa fa-bolt" > < / i > ${_('Delete forever')} < / button > < !-- / ko --> < ul class ="dropdown-menu" > < li > < a href = "#" class ="delete-link" title="${_('Delete forever')}" data-bind="enable: selectedFiles().length > 0, click: deleteSelected" > < i class ="fa fa-bolt" > < / i > ${_('Delete forever')} < / a > < / li > < / ul >4. /usr/lib/hue/apps/filebrowser/src/filebrowser/templates/listdir_components.mako< li > < a href = "#" class ="delete-link" title="${_('Delete forever')}" data-bind="enable: $root.selectedFiles().length > 0, click: $root.deleteSelected" > < i class ="fa fa-fw fa-bolt" > < / i > ${_('Delete forever')} < / a > < / li >5. /usr/lib/hue/apps/filebrowser/src/filebrowser/views.pyrequest.fs.do_as_user(request.user, request.fs.rmtree, arg['path'], True) # the old code was ('skip_trash' in request.GET)修改hdfs配置hdfs-site.xml文件修改：fs.permissions.umask-mode 000(hue建表用户为web登录用户，在用spark做计算引擎时会在hdfs的表目录中创建文件，后台spark的用户为hive无法写入)添加：添加hue用户为hdfs代理用户(superuser)hadoop.proxyuser.hue.hosts *hadoop.proxyuser.hue.groups *

2016-12-28
