对象池 GenericObjectPool 配置参数详解

依赖

    <dependency>
        <groupId>org.apache.commons</groupId>
        <artifactId>commons-pool2</artifactId>
        <version>2.4.3</version>
    </dependency>

使用 GenericObjectPool，有必要了解一下 GenericObjectPoolConfig，下面将说明一下其配置参数。

1. 父类BaseObjectPoolConfig配置参数

/**
 * Provides the implementation for the common attributes shared by the
 * sub-classes. New instances of this class will be created using the defaults
 * defined by the public constants.
 * <p>
 * This class is not thread-safe.
 *  * @since 2.0
 */
public abstract class BaseObjectPoolConfig extends BaseObject implements Cloneable {
    private boolean lifo = DEFAULT_LIFO;

    private boolean fairness = DEFAULT_FAIRNESS;

    private long maxWaitMillis = DEFAULT_MAX_WAIT_MILLIS;

    private long minEvictableIdleTimeMillis = DEFAULT_MIN_EVICTABLE_IDLE_TIME_MILLIS;

    private long evictorShutdownTimeoutMillis = DEFAULT_EVICTOR_SHUTDOWN_TIMEOUT_MILLIS;

    private long softMinEvictableIdleTimeMillis = DEFAULT_SOFT_MIN_EVICTABLE_IDLE_TIME_MILLIS;

    private int numTestsPerEvictionRun = DEFAULT_NUM_TESTS_PER_EVICTION_RUN;

    private String evictionPolicyClassName = DEFAULT_EVICTION_POLICY_CLASS_NAME;

    private boolean testOnCreate = DEFAULT_TEST_ON_CREATE;

    private boolean testOnBorrow = DEFAULT_TEST_ON_BORROW;

    private boolean testOnReturn = DEFAULT_TEST_ON_RETURN;

    private boolean testWhileIdle = DEFAULT_TEST_WHILE_IDLE;

    private long timeBetweenEvictionRunsMillis = DEFAULT_TIME_BETWEEN_EVICTION_RUNS_MILLIS;

    private boolean blockWhenExhausted = DEFAULT_BLOCK_WHEN_EXHAUSTED;

    private boolean jmxEnabled = DEFAULT_JMX_ENABLE;

    private String jmxNamePrefix = DEFAULT_JMX_NAME_PREFIX;

    private String jmxNameBase = DEFAULT_JMX_NAME_BASE;
}

• lifo
  提供了后进先出(LIFO)与先进先出(FIFO)两种行为模式的池；
  默认 DEFAULT_LIFO = true， 当池中有空闲可用的对象时，调用borrowObject方法会返回最近（后进）的实例。
  org.apache.commons.pool2.impl.GenericObjectPool

      if (getLifo()) {
          idleObjects.addFirst(p);
      } else {
          idleObjects.addLast(p);
      }

• fairness
  当从池中获取资源或者将资源还回池中时,是否使用；java.util.concurrent.locks.ReentrantLock.ReentrantLock 的公平锁机制。
  默认DEFAULT_FAIRNESS = false
  org.apache.commons.pool2.impl.GenericObjectPool

  idleObjects = new LinkedBlockingDeque<PooledObject<T>>(config.getFairness());

• maxWaitMillis
  当连接池资源用尽后，调用者获取连接时的最大等待时间（单位 ：毫秒）；
  默认值 DEFAULT_MAX_WAIT_MILLIS = -1L， 永不超时。
  org.apache.commons.pool2.impl.GenericObjectPool

  @Override
  public T borrowObject() throws Exception {
      return borrowObject(getMaxWaitMillis());
  }

• minEvictableIdleTimeMillis
  连接的最小空闲时间，达到此值后该空闲连接可能会被移除（还需看是否已达最大空闲连接数）；
  默认值 DEFAULT_MIN_EVICTABLE_IDLE_TIME_MILLIS = 1000L 60L 30L
  org.apache.commons.pool2.impl.GenericObjectPool

  final EvictionConfig evictionConfig = new EvictionConfig(
                      getMinEvictableIdleTimeMillis(),
                      getSoftMinEvictableIdleTimeMillis(),
                      getMinIdle());

• evictorShutdownTimeoutMillis
  关闭驱逐线程的超时时间；
  默认值 DEFAULT_EVICTOR_SHUTDOWN_TIMEOUT_MILLIS = 10L * 1000L
  org.apache.commons.pool2.impl.BaseGenericObjectPool

  final void startEvictor(final long delay) {
      synchronized (evictionLock) {
          if (null != evictor) {
              EvictionTimer.cancel(evictor, evictorShutdownTimeoutMillis, TimeUnit.MILLISECONDS);
              evictor = null;
              evictionIterator = null;
          }
          if (delay > 0) {
              evictor = new Evictor();
              EvictionTimer.schedule(evictor, delay, delay);
          }
      }
  }

• softMinEvictableIdleTimeMillis
  连接空闲的最小时间，达到此值后空闲链接将会被移除，且保留minIdle个空闲连接数；
  默认值 DEFAULT_SOFT_MIN_EVICTABLE_IDLE_TIME_MILLIS = -1

• numTestsPerEvictionRun
  检测空闲对象线程每次运行时检测的空闲对象的数量；
  如果 numTestsPerEvictionRun>=0, 则取numTestsPerEvictionRun 和池内的连接数 的较小值 作为每次检测的连接数；
  如果 numTestsPerEvictionRun<0，则每次检查的连接数是检查时池内连接的总数除以这个值的绝对值再向上取整的结果；
  默认值 DEFAULT_NUM_TESTS_PER_EVICTION_RUN = 3
  org.apache.commons.pool2.impl.GenericObjectPool

      private int getNumTests() {
          final int numTestsPerEvictionRun = getNumTestsPerEvictionRun();
          if (numTestsPerEvictionRun >= 0) {
              return Math.min(numTestsPerEvictionRun, idleObjects.size());
          }
          return (int) (Math.ceil(idleObjects.size() /
                  Math.abs((double) numTestsPerEvictionRun)));
      }

• evictionPolicyClassName
  驱逐策略的类名；
  默认值 DEFAULT_EVICTION_POLICY_CLASS_NAME = "org.apache.commons.pool2.impl.DefaultEvictionPolicy"
  org.apache.commons.pool2.impl.GenericObjectPool

     public final void setEvictionPolicyClassName(final String evictionPolicyClassName) {
          try {
              Class<?> clazz;
              try {
                  clazz = Class.forName(evictionPolicyClassName, true, Thread.currentThread().getContextClassLoader());
              } catch (final ClassNotFoundException e) {
                  clazz = Class.forName(evictionPolicyClassName);
              }
              final Object policy = clazz.newInstance();
              if (policy instanceof EvictionPolicy<?>) {
                  @SuppressWarnings("unchecked") // safe, because we just checked the class
                  final EvictionPolicy<T> evicPolicy = (EvictionPolicy<T>) policy;
                  this.evictionPolicy = evicPolicy;
              } else {
                  throw new IllegalArgumentException("[" + evictionPolicyClassName + "] does not implement EvictionPolicy");
              }
          } catch (final ClassNotFoundException e) {
              throw new IllegalArgumentException("Unable to create EvictionPolicy instance of type " + evictionPolicyClassName, e);
          } catch (final InstantiationException e) {
              throw new IllegalArgumentException("Unable to create EvictionPolicy instance of type " + evictionPolicyClassName, e);
          } catch (final IllegalAccessException e) {
              throw new IllegalArgumentException("Unable to create EvictionPolicy instance of type " + evictionPolicyClassName, e);
          }
      }

• testOnCreate
  在创建对象时检测对象是否有效(true : 是) , 配置true会降低性能；
  默认值 DEFAULT_TEST_ON_CREATE = false。
  org.apache.commons.pool2.impl.GenericObjectPool##borrowObject(final long borrowMaxWaitMillis)

      PooledObject<T> p = null;
      // ...省略
      // 配置true，新创建对象都会检测对象是否有效 【 create && getTestOnCreate() 】
      if (p != null && (getTestOnBorrow() || create && getTestOnCreate())) {
          boolean validate = false;
          Throwable validationThrowable = null;
          try {
              validate = factory.validateObject(p);
          } catch (final Throwable t) {
              PoolUtils.checkRethrow(t);
              validationThrowable = t;
          }
          if (!validate) {
              try {
                  destroy(p);
                  destroyedByBorrowValidationCount.incrementAndGet();
              } catch (final Exception e) {
                  // Ignore - validation failure is more important
              }
              p = null;
              if (create) {
                  final NoSuchElementException nsee = new NoSuchElementException("Unable to validate object");
                  nsee.initCause(validationThrowable);
                  throw nsee;
              }
          }
      }

• testOnBorrow
  在从对象池获取对象时是否检测对象有效(true : 是) , 配置true会降低性能；
  默认值 DEFAULT_TEST_ON_BORROW = false
  org.apache.commons.pool2.impl.GenericObjectPool##borrowObject(final long borrowMaxWaitMillis)**

  // 配置true，从对象池获取对象，总是要检测对象是否有效 【 getTestOnBorrow() 】
  if (p != null && (getTestOnBorrow() || create && getTestOnCreate())) {
      // ...省略
  }

• testOnReturn
  在向对象池中归还对象时是否检测对象有效(true : 是) , 配置true会降低性能；
  默认值 DEFAULT_TEST_ON_RETURN = false
  org.apache.commons.pool2.impl.GenericObjectPool##returnObject(final T obj)

      if (getTestOnReturn()) {
          if (!factory.validateObject(p)) {
              try {
                  destroy(p);
              } catch (final Exception e) {
                  swallowException(e);
              }
              try {
                  ensureIdle(1, false);
              } catch (final Exception e) {
                  swallowException(e);
              }
              updateStatsReturn(activeTime);
              return;
          }
      }

• testWhileIdle
  在检测空闲对象线程检测到对象不需要移除时，是否检测对象的有效性。建议配置为true，不影响性能，并且保证安全性；
  默认值 DEFAULT_TEST_WHILE_IDLE = false
  org.apache.commons.pool2.impl.GenericObjectPool##evict()

      final boolean testWhileIdle = getTestWhileIdle();
      // .... 代码省略
      // 配置为true， 检测空闲对象线程检测到对象不需要移除时，检测对象的有效性
      if (testWhileIdle) {
          boolean active = false;
          try {
              factory.activateObject(underTest);
              active = true;
          } catch (final Exception e) {
              destroy(underTest);
              destroyedByEvictorCount.incrementAndGet();
          }
          if (active) {
              if (!factory.validateObject(underTest)) {
                  destroy(underTest);
                  destroyedByEvictorCount.incrementAndGet();
              } else {
                  try {
                      factory.passivateObject(underTest);
                  } catch (final Exception e) {
                      destroy(underTest);
                      destroyedByEvictorCount.incrementAndGet();
                  }
              }
          }
      }

• timeBetweenEvictionRunsMillis
  空闲连接检测的周期（单位毫秒）；如果为负值，表示不运行检测线程；
  默认值 DEFAULT_TIME_BETWEEN_EVICTION_RUNS_MILLIS = -1L
  org.apache.commons.pool2.impl.GenericObjectPool

      public GenericObjectPool(final PooledObjectFactory<T> factory, final GenericObjectPoolConfig config) {
          super(config, ONAME_BASE, config.getJmxNamePrefix());
          if (factory == null) {
              jmxUnregister(); // tidy up
              throw new IllegalArgumentException("factory may not be null");
          }
          this.factory = factory;

          idleObjects = new LinkedBlockingDeque<PooledObject<T>>(config.getFairness());

          setConfig(config);
          // 启动空闲连接检测线程
          startEvictor(getTimeBetweenEvictionRunsMillis());
      }

• blockWhenExhausted
  当对象池没有空闲对象时，新的获取对象的请求是否阻塞（true 阻塞，maxWaitMillis 才生效； false 连接池没有资源立马抛异常）
  默认值 DEFAULT_BLOCK_WHEN_EXHAUSTED = true
  org.apache.commons.pool2.impl.GenericObjectPool##borrowObject(final long borrowMaxWaitMillis)

      final boolean blockWhenExhausted = getBlockWhenExhausted();
      // ... 省略
      if (blockWhenExhausted) {
          if (p == null) {
              if (borrowMaxWaitMillis < 0) {
                  p = idleObjects.takeFirst();
              } else {
                  p = idleObjects.pollFirst(borrowMaxWaitMillis,
                          TimeUnit.MILLISECONDS);
              }
          }
          if (p == null) {
              throw new NoSuchElementException(
                      "Timeout waiting for idle object");
          }
      }

• jmxEnabled
  是否注册JMX
  默认值 DEFAULT_JMX_ENABLE = true
  org.apache.commons.pool2.impl.BaseGenericObjectPool

      public BaseGenericObjectPool(final BaseObjectPoolConfig config, final String jmxNameBase, final String jmxNamePrefix) {
          if (config.getJmxEnabled()) {
              this.oname = jmxRegister(config, jmxNameBase, jmxNamePrefix);
          } else {
              this.oname = null;
          }

          // Populate the creation stack trace
          this.creationStackTrace = getStackTrace(new Exception());

          // save the current TCCL (if any) to be used later by the evictor Thread
          final ClassLoader cl = Thread.currentThread().getContextClassLoader();
          if (cl == null) {
              factoryClassLoader = null;
          } else {
              factoryClassLoader = new WeakReference<ClassLoader>(cl);
          }

          fairness = config.getFairness();
      }

• jmxNamePrefix
  JMX前缀
  默认值 DEFAULT_JMX_NAME_PREFIX = "pool"
  org.apache.commons.pool2.impl.GenericObjectPool

      // JMX specific attributes
      private static final String ONAME_BASE = "org.apache.commons.pool2:type=GenericObjectPool,name=";

      public GenericObjectPool(final PooledObjectFactory<T> factory, final GenericObjectPoolConfig config) {
          // 参见上述 jmxEnabled 部分
          super(config, ONAME_BASE, config.getJmxNamePrefix());
          // .....
      }

• jmxNameBase
  使用 base + jmxNamePrefix + i 来生成ObjectName
  默认值 DEFAULT_JMX_NAME_BASE = null，GenericObjectPool 构造方法使用 ONAME_BASE 初始化。

      private ObjectName jmxRegister(final BaseObjectPoolConfig config,final String jmxNameBase, String jmxNamePrefix) {
          ObjectName objectName = null;
          final MBeanServer mbs = ManagementFactory.getPlatformMBeanServer();
          int i = 1;
          boolean registered = false;
          String base = config.getJmxNameBase();
          if (base == null) {
              base = jmxNameBase;
          }
          while (!registered) {
              try {
                  ObjectName objName;
                  if (i == 1) {
                      objName = new ObjectName(base + jmxNamePrefix);
                  } else {
                      objName = new ObjectName(base + jmxNamePrefix + i);
                  }
                  mbs.registerMBean(this, objName);
                  objectName = objName;
                  registered = true;
              } catch (final MalformedObjectNameException e) {
                  if (BaseObjectPoolConfig.DEFAULT_JMX_NAME_PREFIX.equals(jmxNamePrefix) && jmxNameBase.equals(base)) {
                      // 如果走到这步，就跳过jmx注册，应该不会发生
                      registered = true;
                  } else {
                      // 前者使用的名称不是默认配置，则使用默认配置替代
                      jmxNamePrefix =
                              BaseObjectPoolConfig.DEFAULT_JMX_NAME_PREFIX;
                      base = jmxNameBase;
                  }
              } catch (final InstanceAlreadyExistsException e) {
                  // 增加一个索引，再试一次
                  i++;
              } catch (final MBeanRegistrationException e) {
                  // 如果走到这步，就跳过jmx注册，应该不会发生
                  registered = true;
              } catch (final NotCompliantMBeanException e) {
                  // 如果走到这步，就跳过jmx注册，应该不会发生
                  registered = true;
              }
          }
          return objectName;
      }


2. 子类GenericObjectPoolConfig配置参数

/**
 * A simple "struct" encapsulating the configuration for a
 * {@link GenericObjectPool}.
 *  * <p>
 * This class is not thread-safe; it is only intended to be used to provide
 * attributes used when creating a pool.
 *  * @since 2.0
 */
public class GenericObjectPoolConfig extends BaseObjectPoolConfig {

    private int maxTotal = DEFAULT_MAX_TOTAL;

    private int maxIdle = DEFAULT_MAX_IDLE;

    private int minIdle = DEFAULT_MIN_IDLE;
}

• maxTotal
  最大连接数，默认值 DEFAULT_MAX_TOTAL = 8
• maxIdle
  最大空闲连接数， 默认值 DEFAULT_MAX_IDLE = 8
• minIdle
  最小空闲连接数， 默认值 DEFAULT_MIN_IDLE = 0
