崛起于Springboot2.0.X之集成规则引擎Drools(41)

1、创建Springboot项目

2、添加pom其他依赖

<dependency> <groupId>org.kie</groupId> <artifactId>kie-spring</artifactId> <version>7.11.0.Final</version> <exclusions> <exclusion> <groupId>org.springframework</groupId> <artifactId>spring-tx</artifactId> </exclusion> <exclusion> <groupId>org.springframework</groupId> <artifactId>spring-beans</artifactId> </exclusion> <exclusion> <groupId>org.springframework</groupId> <artifactId>spring-core</artifactId> </exclusion> <exclusion> <groupId>org.springframework</groupId> <artifactId>spring-context</artifactId> </exclusion> </exclusions> </dependency> <dependency> <groupId>org.drools</groupId> <artifactId>drools-compiler</artifactId> <version>7.11.0.Final</version> </dependency>

3、创建实体类

@Data public class Address { private String postCode; private String street; private String state; }

@Data public class AddressCheckResult { //true通过校验，false 未通过 private boolean postCodeResult = false; }

4、配置类

import org.kie.api.KieBase; import org.kie.api.KieServices; import org.kie.api.builder.*; import org.kie.api.runtime.KieContainer; import org.kie.api.runtime.KieSession; import org.kie.internal.io.ResourceFactory; import org.kie.spring.KModuleBeanFactoryPostProcessor; import org.springframework.boot.autoconfigure.condition.ConditionalOnMissingBean; import org.springframework.context.annotation.Bean; import org.springframework.context.annotation.Configuration; import org.springframework.core.io.Resource; import org.springframework.core.io.support.PathMatchingResourcePatternResolver; import org.springframework.core.io.support.ResourcePatternResolver; import java.io.IOException; @Configuration public class DroolsAutoConfiguration { //rule的存放位置 private static final String RULES_PATH = "rules/"; @Bean @ConditionalOnMissingBean(KieFileSystem.class) public KieFileSystem kieFileSystem() throws IOException { KieFileSystem kieFileSystem = getKieServices().newKieFileSystem(); for (Resource file : getRuleFiles()) { String path = RULES_PATH + file.getFilename(); kieFileSystem.write(ResourceFactory.newClassPathResource(path, "UTF-8")); } return kieFileSystem; } /** * 这里要引入 org.springframework.core.io.Resource 包 * * @return * @throws IOException */ private Resource[] getRuleFiles() throws IOException { ResourcePatternResolver resourcePatternResolver = new PathMatchingResourcePatternResolver(); return resourcePatternResolver.getResources("classpath*:" + RULES_PATH + "**/*.*"); } @Bean @ConditionalOnMissingBean(KieContainer.class) public KieContainer kieContainer() throws IOException { final KieRepository kieRepository = getKieServices().getRepository(); kieRepository.addKieModule(new KieModule() { public ReleaseId getReleaseId() { return kieRepository.getDefaultReleaseId(); } }); KieBuilder kieBuilder = getKieServices().newKieBuilder(kieFileSystem()); kieBuilder.buildAll(); return getKieServices().newKieContainer(kieRepository.getDefaultReleaseId()); } private KieServices getKieServices() { return KieServices.Factory.get(); } @Bean @ConditionalOnMissingBean(KieBase.class) public KieBase kieBase() throws IOException { return kieContainer().getKieBase(); } @Bean @ConditionalOnMissingBean(KieSession.class) public KieSession kieSession() throws IOException { return kieContainer().newKieSession(); } @Bean @ConditionalOnMissingBean(KModuleBeanFactoryPostProcessor.class) public KModuleBeanFactoryPostProcessor kiePostProcessor() { return new KModuleBeanFactoryPostProcessor(); } }

5、创建drools特有的xml

<?xml version="1.0" encoding="UTF-8" ?> <kmodule xmlns="http://www.drools.org/xsd/kmodule"> <kbase name="rules" packages="mujiutian.rules"> <ksession name="ksession-rule"/> </kbase> </kmodule>

      这个packages 要和下面的规则文件对应的名字一致，不然会报错。

6、编写drools规则

package mujiutian.rules; import com.mjt.drools.entity.Address; import com.mjt.drools.entity.AddressCheckResult; rule "Rules" when adress : Address(postCode != null,postCode matches "([0-9]{5})") checkResult: AddressCheckResult(); then checkResult.setPostCodeResult(true); System.out.println("规则中打印日志：校验通过"); end

      这个package默认生成是static，要修改一些，不然会报错，同时要和上面xml中的内容一样才行，rule 后面加的"" 是描述内容，可以写任何内容。

7、编写controller层

import org.kie.api.runtime.KieSession; import org.springframework.web.bind.annotation.GetMapping; import org.springframework.web.bind.annotation.RequestMapping; import org.springframework.web.bind.annotation.RestController; import javax.annotation.Resource; @RestController @RequestMapping(value = "/drools") public class DroolsController { @Resource KieSession kieSession; @GetMapping(value = "/address") public void test1(){ Address address = new Address(); address.setPostCode("99425"); AddressCheckResult result = new AddressCheckResult(); kieSession.insert(address); kieSession.insert(result); int ruleFiredCount = kieSession.fireAllRules(); System.out.println("触发了"+ruleFiredCount+"条规则"); if (result.isPostCodeResult()){ System.out.println("规则校验通过"); } } }

8、运行测试

      借鉴于：https://blog.csdn.net/qq_21383435/article/details/82873711  基本完全复制的代码，如果可以也可以进入他的博客专栏,感谢！

      ok～
