android recyclerview+GalleryLayoutManager 实现广告画廊效果
image 相信大家平常在项目中遇到过画廊的效果，网上也有多种方式，类似viewPager、recyclerview等等方式实现，今天推荐一个三方库GalleryLayoutManager，便于快速实现，以解燃眉之急。 image 依赖 gradle依赖 compile 'github.hellocsl:GalleryLayoutManager:1.0.6' 实现 布局文件 <?xml version="1.0" encoding="utf-8"?> <RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android" android:layout_width="match_parent" android:layout_height="match_parent"> <android.support.v7.widget.RecyclerView android:id="@+id/recycler" android:layout_width="match_parent" android:layout_height="match_parent" /> </RelativeLayout> recyclerView设置的adapter private class Adapter extends RecyclerView.Adapter<RecyclerHolder> { private Context context; private Adapter(Context context) { this.context = context; } @Override public RecyclerHolder onCreateViewHolder(ViewGroup parent, int viewType) { View view = LayoutInflater.from(context).inflate(R.layout.item_view, null); //自定义view的宽度，控制一屏显示个数 LinearLayout.LayoutParams params = new LinearLayout.LayoutParams(LinearLayout.LayoutParams.WRAP_CONTENT, LinearLayout.LayoutParams.WRAP_CONTENT); int width = context.getResources().getDisplayMetrics().widthPixels; params.width = width / 3; view.setLayoutParams(params); return new RecyclerHolder(view); } @Override public void onBindViewHolder(RecyclerHolder holder, int position) { } @Override public int getItemCount() { return 10; } } private class RecyclerHolder extends RecyclerView.ViewHolder { private View view; public RecyclerHolder(View itemView) { super(itemView); view = itemView; } public View getView() { return view; } } 每个item简单的放置一个布局 <?xml version="1.0" encoding="utf-8"?> <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android" android:layout_width="wrap_content" android:layout_height="wrap_content" android:gravity="center" android:orientation="vertical"> <ImageView android:layout_width="100dp" android:layout_height="wrap_content" android:src="@mipmap/dota" /> </LinearLayout> 采用第三方的GalleryLayoutManager 与 recyclerView绑定，设置为横向滑动布局 GalleryLayoutManager manager = new GalleryLayoutManager(GalleryLayoutManager.HORIZONTAL); manager.attach(recycler); //设置滑动缩放效果 manager.setItemTransformer(new Transformer()); recycler.setAdapter(new Adapter(this)); 缩放效果处理 //滑动过程中的缩放 public class Transformer implements GalleryLayoutManager.ItemTransformer { @Override public void transformItem(GalleryLayoutManager layoutManager, View item, float fraction) { //以圆心进行缩放 item.setPivotX(item.getWidth() / 2.0f); item.setPivotY(item.getHeight() / 2.0f); float scale = 1 - 0.3f * Math.abs(fraction); item.setScaleX(scale); item.setScaleY(scale); } } 可以自定义RecyclerView里每项view的宽度，控制一屏显示效果，adapter的onCreateViewHolder里操作 @Override public RecyclerView.ViewHolder onCreateViewHolder(ViewGroup parent, int viewType) { View view = LayoutInflater.from(context).inflate(R.layout.item_view, null); //自定义view的宽度，控制一屏显示个数 LinearLayout.LayoutParams params = new LinearLayout.LayoutParams(LinearLayout.LayoutParams.WRAP_CONTENT, LinearLayout.LayoutParams.WRAP_CONTENT); int width = context.getResources().getDisplayMetrics().widthPixels; params.width = width / 3; view.setLayoutParams(params); return new RecyclerHolder(view); } image 滑动监听 滑动监听最终停止的位置 manager.setOnItemSelectedListener(new GalleryLayoutManager.OnItemSelectedListener() { @Override public void onItemSelected(RecyclerView recyclerView, View item, int position) { //滑动到某一项的position } }); 同时支持点击每一项滑动切换，adapter的onBindViewHolder方法里 @Override public void onBindViewHolder(RecyclerHolder holder, final int position) { holder.getView().setOnClickListener(new View.OnClickListener() { @Override public void onClick(View v) { recycler.smoothScrollToPosition(position); } }); } 至此，一个简单的画廊效果实现，如果你项目正好需要这个，而我正好有。 当然这里只是简单介绍了画廊效果的实现，这个库还提供支持上下滑动的效果，贴上github地址 https://github.com/BCsl/GalleryLayoutManager， 便于大家进一步研究 同时欢迎关注微信公众号 image.png
