// mybatis初始化
String resource = "mybatis-config.xml";
InputStream inputStream = Resources.getResourceAsStream(resource);
SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder().build(inputStream);
// 创建SqlSession
SqlSession sqlSession = sqlSessionFactory.openSession();
// 执行SQL语句
List list = sqlSession.selectList("com.foo.bean.BlogMapper.queryAllBlogInfo");

public SqlSessionFactory build(InputStream inputStream) {
 return build(inputStream, null, null);
}
public SqlSessionFactory build(InputStream inputStream, String environment, Properties properties) {
 try {
 //2. 创建XMLConfigBuilder对象用来解析XML配置文件，生成Configuration对象
 XMLConfigBuilder parser = new XMLConfigBuilder(inputStream, environment, properties);
 //3. 将XML配置文件内的信息解析成Java对象Configuration对象
 Configuration config = parser.parse();
 //4. 根据Configuration对象创建出SqlSessionFactory对象
 return build(config);
 } catch (Exception e) {
 throw ExceptionFactory.wrapException("Error building SqlSession.", e);
 } finally {
 ErrorContext.instance().reset();
 try {
 inputStream.close();
 } catch (IOException e) {
 // Intentionally ignore. Prefer previous error.
 }
 }
}
// 从此处可以看出，MyBatis内部通过Configuration对象来创建SqlSessionFactory,用户也可以自己通过API构造好Configuration对象，调用此方法创SqlSessionFactory
public SqlSessionFactory build(Configuration config) {
 return new DefaultSqlSessionFactory(config);
}

public Configuration parse() {
 if (parsed) {
 throw new BuilderException("Each XMLConfigBuilder can only be used once.");
 }
    parsed = true;
 //源码中没有这一句，只有 parseConfiguration(parser.evalNode("/configuration"));
 //为了让读者看得更明晰，源码拆分为以下两句
 XNode configurationNode = parser.evalNode("/configuration");
 parseConfiguration(configurationNode);
 return configuration;
}
/**
 * 解析 "/configuration"节点下的子节点信息，然后将解析的结果设置到Configuration对象中
 */
private void parseConfiguration(XNode root) {
 try {
 //1.首先处理properties 节点
 propertiesElement(root.evalNode("properties")); //issue #117 read properties first
 //2.处理typeAliases
 typeAliasesElement(root.evalNode("typeAliases"));
 //3.处理插件
 pluginElement(root.evalNode("plugins"));
 //4.处理objectFactory
 objectFactoryElement(root.evalNode("objectFactory"));
 //5.objectWrapperFactory
 objectWrapperFactoryElement(root.evalNode("objectWrapperFactory"));
 //6.settings
 settingsElement(root.evalNode("settings"));
 //7.处理environments
 environmentsElement(root.evalNode("environments")); // read it after objectFactory and objectWrapperFactory issue #631
 //8.database
 databaseIdProviderElement(root.evalNode("databaseIdProvider"));
 //9.typeHandlers
 typeHandlerElement(root.evalNode("typeHandlers"));
 //10.mappers
 mapperElement(root.evalNode("mappers"));
 } catch (Exception e) {
 throw new BuilderException("Error parsing SQL Mapper Configuration. Cause: " + e, e);
 }
}

/**
 * 解析environments节点，并将结果设置到Configuration对象中
 * 注意：创建envronment时，如果SqlSessionFactoryBuilder指定了特定的环境（即数据源）；
 *      则返回指定环境（数据源）的Environment对象，否则返回默认的Environment对象；
 *      这种方式实现了MyBatis可以连接多数据源
 */
private void environmentsElement(XNode context) throws Exception {
 if (context != null)
 {
 if (environment == null)
 {
            environment = context.getStringAttribute("default");
 }
 for (XNode child : context.getChildren())
 {
 String id = child.getStringAttribute("id");
 if (isSpecifiedEnvironment(id))
 {
 //1.创建事务工厂 TransactionFactory
 TransactionFactory txFactory = transactionManagerElement(child.evalNode("transactionManager"));
 DataSourceFactory dsFactory = dataSourceElement(child.evalNode("dataSource"));
 //2.创建数据源DataSource
 DataSource dataSource = dsFactory.getDataSource();
 //3. 构造Environment对象
 Environment.Builder environmentBuilder = new Environment.Builder(id)
 .transactionFactory(txFactory)
 .dataSource(dataSource);
 //4. 将创建的Envronment对象设置到configuration 对象中
 configuration.setEnvironment(environmentBuilder.build());
 }
 }
 }
}
private boolean isSpecifiedEnvironment(String id)
{
 if (environment == null)
 {
 throw new BuilderException("No environment specified.");
 }
 else if (id == null)
 {
 throw new BuilderException("Environment requires an id attribute.");
 }
 else if (environment.equals(id))
 {
 return true;
 }
 return false;
}

String resource = "mybatis-config.xml";
InputStream inputStream = Resources.getResourceAsStream(resource);
// 手动创建XMLConfigBuilder，并解析创建Configuration对象
XMLConfigBuilder parser = new XMLConfigBuilder(inputStream, null,null); // 看这里
Configuration configuration = parser.parse();
// 使用Configuration对象创建SqlSessionFactory
SqlSessionFactory sqlSessionFactory = new SqlSessionFactoryBuilder().build(configuration);
// 使用MyBatis
SqlSession sqlSession = sqlSessionFactory.openSession();
List list = sqlSession.selectList("com.foo.bean.BlogMapper.queryAllBlogInfo");
