在Docker – 系统整洁之道 – 1中已经对Docker的一些命令和Docker镜像的使用及操作做了记录。
这次就利用docker进行一次真正的实例使用，使用docker搭建一个简单的答题系统，这个系统是当时做来给网络安全周做手机答题的系统，很简单，代码风格很差。

这篇主要记录了三种docker使用的方式。

• 用supervisor方式运行一个多进程的docker实例
• 创建一个ngnix和php运行的环境
• 创建一个ngnix，php，mysql集合运行的环境，使用docker-compose构建

感觉docker的东西越看越多，从刚开始的简简单单的一个docker run，到现在看到要build自己的镜像，compose,也就是以前的Fig，配置网络，还有swarm的docker集群，一点一点来吧。

先把两个附件写在这里吧
此片博客中构建php+ngnix+mysql测试环境的脚本
在测试环境中的答题网站源码

supervisor方式运行一个多进程的docker实例

---

Docker 容器在启动的时候开启单个进程，比如，一个 ssh 或者 apache 的 daemon 服务。但我们经常需要在一个机器上开启多个服务，这可以有很多方法，最简单的就是把多个启动命令放到一个启动脚本里面，启动的时候直接启动这个脚本，另外就是安装进程管理工具。这里使用进程管理工具 supervisor 来管理容器中的多个进程。使用 Supervisor 可以更好的控制、管理、重启我们希望运行的进程。

首先创一个文件夹叫做supervisor,目录结构为

~/Docker tree supervisor
supervisor
├── Dockerfile
└── supervisord

其中文件Dockerfile文件内容为：

#使用时哪个镜像
FROM ubuntu:13.04
MAINTAINER examples@docker.com
RUN echo "deb http://archive.ubuntu.com/ubuntu precise main universe" > /etc/apt/sources.list
RUN apt-get update
RUN apt-get upgrade -y

#这里安装 3 个软件，还创建了 2 个 ssh 和 supervisor 服务正常运行所需要的目录。
RUN apt-get install -y --force-yes perl-base=5.14.2-6ubuntu2
RUN apt-get install -y apache2.2-common
RUN apt-get install -y openssh-server apache2 supervisor
RUN mkdir -p /var/run/sshd
RUN mkdir -p /var/log/supervisor

#添加 supervisord 的配置文件，并复制配置文件到对应目录下面。
COPY supervisord.conf /etc/supervisor/conf.d/supervisord.conf

#映射了 22 和 80 端口，使用 supervisord 的可执行路径启动服务
EXPOSE 22 80
CMD ["/usr/bin/supervisord"]

文件supervisord内容为：

#supervsord 配置软件本身，使用 nodaemon 参数来运行
[supervisord]
nodaemon=true

#配置两个服务
[program:sshd]
command=/usr/sbin/sshd -D
[program:apache2]
command=/bin/bash -c "source /etc/apache2/envvars && exec /usr/sbin/apache2 -DFOREGROUND"

使用命令进行构建

sudo docker build -t supervisor

输出：

~/Docker/supervisor  sudo docker build -t supervisord .
Password:
Sending build context to Docker daemon 3.584 kB
Step 1 : FROM ubuntu:13.04
---> a58cd502f927
Step 2 : MAINTAINER examples@docker.com
---> Using cache
---> 15f104cdeb77
Step 3 : RUN echo "deb http://archive.ubuntu.com/ubuntu precise main universe" > /etc/apt/sources.list
---> Using cache
---> c6bb44d794ea
Step 4 : RUN apt-get update
---> Using cache
---> adcd83eecb0d
Step 5 : RUN apt-get upgrade -y
---> Using cache
---> 89e045811261
Step 6 : RUN apt-get install -y --force-yes perl-base=5.14.2-6ubuntu2
---> Using cache
---> bcdc472cc73a
Step 7 : RUN apt-get install -y apache2.2-common
---> Using cache
---> d8991f8aa3c6
Step 8 : RUN apt-get install -y openssh-server apache2 supervisor
---> Using cache
---> a713034800d6
Step 9 : RUN mkdir -p /var/run/sshd
---> Using cache
---> 3138e3644958
Step 10 : RUN mkdir -p /var/log/supervisor
---> Using cache
---> 958c08978b0c
Step 11 : COPY supervisord.conf /etc/supervisor/conf.d/supervisord.conf
---> 8e9a0c97a133
Removing intermediate container d95b58057f73
Step 12 : EXPOSE 22 80
---> Running in 9cabb0865159
---> b4aa8b82cd57
Removing intermediate container 9cabb0865159
Step 13 : CMD /usr/bin/supervisord
---> Running in 237f71166211
---> 569f95736129
Removing intermediate container 237f71166211
Successfully built 569f95736129

使用docker ps 一下

~/Docker/supervisor  docker ps
CONTAINER ID        IMAGE                COMMAND                  CREATED             STATUS              PORTS                                          NAMES
c82c830770bc        supervisord:latest   "/usr/bin/supervisord"   32 seconds ago      Up 30 seconds       0.0.0.0:32770->22/tcp, 0.0.0.0:32769->80/tcp   supervisord

发现刚才build的镜像已经跑起来了，访问 http://127.0.0.1:32769，可以web服务已经跑起来了。

使用命令docker exec进入container里面看看

 ~/Docker/supervisor  docker exec -it c82c830770bc bash
root@c82c830770bc:/# hello
bash: hello: command not found
root@c82c830770bc:/# ls
bin  boot  dev  etc  home  lib  lib64  media  mnt  opt  proc  root  run  sbin  selinux  srv  sys  tmp  usr  var
root@c82c830770bc:/#

使用passwd修改一下密码，然后在本机的命令行里进行ssh连接吧。

ngnix和php运行的环境

---

该方法就是直接使用docker命令进行构建一个ngnix,php结合运行的环境，没有使用docker-compose。

先用户根目录~下创建目录，并将该目录设置为Docker的共享目录。

Workspace
└── tmp
    ├── docker
    │   └── nginx
    │       └── conf.d
    │           └── default.conf
    └── www
        ├── index.html
        └── phpinfo.php

其中default.conf文件内容，这是个nginx的配置文件

server {
    listen       80;
    server_name  localhost;

    location / {
        root   /usr/share/nginx/html;
        index  index.html index.htm;
    }

    error_page   500 502 503 504  /50x.html;
    location = /50x.html {
        root   /usr/share/nginx/html;
    }

    location ~ \.php$ {
        fastcgi_pass   php:9000;
        fastcgi_index  index.php;
        fastcgi_param  SCRIPT_FILENAME  /var/www/html/$fastcgi_script_name;
        include        fastcgi_params;
    }
}

index.html 里写一句 HelloW0rld，phpinfo.php里面写一个<?php phpinfo();?>。

然后在命令行下执行命令

docker pull php:5.6-fpm-alpine

docker pull ngnix:1.10.2

docker run --name dream.php -d -v ~/Workspace/tmp/www:/var/www/html:ro php:5.6-fpm

docker run --name dream.nginx -p 80:80 -d -v ~/Workspace/tmp/www:/usr/share/nginx/html:ro -v ~/Workspace/tmp/docker/nginx/conf.d:/etc/nginx/conf.d:ro --link dream.php:php nginx:1.10.2

好的，如果不出意外，就可以看到phpinfo的界面了。这个是没有添加mysql的测试环境，直接在目录~/Workspace/tmp/www下面放网页就可以直接使用了。

ngnix，php，mysql集合运行的环境

---

Supervisor给出了一种能够在container中运行多个线程的方法，但是现在还是不知道要怎么样把自己的web服务部署到container中，数据库怎么建，可以有人会说直接使用SFTP将网站直接传到container里，安装数据库，配环境，但是docker中一旦container被删除，内容就没了。像这样将所有服务放在一个容器内的模式有个形象的非官方称呼：Fat Container。与之相对的是将服务分拆到容器的模式。从Docker的设计可以看到，构建镜像的过程中可以指定唯一一个容器启动的指令，因此Docker天然适合一个容器只运行一种服务，而这也是官方更推崇的。下面就记录一下部署一个简单的php程序和数据库联动的测试环境。

整体的文件结构是这样的
我们创建一个这样的目录

Docker
└── test
    ├── data  数据库文件夹
    │   └── mysql
    ├── docker-compose.yml docker-compose配置文件
    ├── htdocs 网站文件夹
    │   ├── index.html
    │   └── index.php
    ├── log 日志文件
    │   └── nginx
    ├── mysql mysql构建文件
    │   └── Dockerfile
    ├── nginx nginx构建文件
    │   ├── Dockerfile
    │   ├── conf.d
    │   │   └── default.conf
    │   └── nginx.conf
    └── php php构建文件
        └── Dockerfile

mysql 独立部署

---

mysql目录下的Dockerfile文件只有一行FROM mysql:5.6，也就是直接使用mysql官方镜像5.6，然后使用命令

docker build -t phpenv/mysql mysql

构建自己的镜像phpenv/mysql。
使用命令

docker run -p 3306:3306 -v ~/Docker/test/data/mysql:/var/lib/mysql -e MYSQL_ROOT_PASSWORD=123456 -it phpenv/mysql

启动镜像，将容器的3306端口绑定到本机的3306端口，其中参数-v后代表使用~/Docker/test/data/mysql挂在到镜像的/var/lib/mysql，也就是替代源镜像的数据库文件目录，让数据库文件目录暴露在本机上，做到数据库内容的持久化。MYSQL_ROOT_PASSWORD为设置mysql的一个root密码。

运行结果

~/Docker/test docker run -p 3306:3306 -v ~/Docker/test/data/mysql:/var/lib/mysql -e MYSQL_ROOT_PASSWORD=123456 -it phpenv/mysql
2016-12-27 15:06:49 0 [Note] mysqld (mysqld 5.6.35) starting as process 1 ...
2016-12-27 15:06:49 1 [Warning] Setting lower_case_table_names=2 because file system for /var/lib/mysql/ is case insensitive
2016-12-27 15:06:49 1 [Note] Plugin 'FEDERATED' is disabled.
2016-12-27 15:06:49 1 [Note] InnoDB: Using atomics to ref count buffer pool pages
2016-12-27 15:06:49 1 [Note] InnoDB: The InnoDB memory heap is disabled
2016-12-27 15:06:49 1 [Note] InnoDB: Mutexes and rw_locks use GCC atomic builtins
2016-12-27 15:06:49 1 [Note] InnoDB: Memory barrier is not used
2016-12-27 15:06:49 1 [Note] InnoDB: Compressed tables use zlib 1.2.8
2016-12-27 15:06:49 1 [Note] InnoDB: Using Linux native AIO
2016-12-27 15:06:49 1 [Note] InnoDB: Using CPU crc32 instructions
2016-12-27 15:06:49 1 [Note] InnoDB: Initializing buffer pool, size = 128.0M
2016-12-27 15:06:49 1 [Note] InnoDB: Completed initialization of buffer pool
2016-12-27 15:06:49 1 [Note] InnoDB: Highest supported file format is Barracuda.
2016-12-27 15:06:49 1 [Note] InnoDB: 128 rollback segment(s) are active.
2016-12-27 15:06:49 1 [Note] InnoDB: Waiting for purge to start
2016-12-27 15:06:49 1 [Note] InnoDB: 5.6.35 started; log sequence number 1626027
2016-12-27 15:06:49 1 [Note] Server hostname (bind-address): '*'; port: 3306
2016-12-27 15:06:49 1 [Note] IPv6 is available.
2016-12-27 15:06:49 1 [Note]   - '::' resolves to '::';
2016-12-27 15:06:49 1 [Note] Server socket created on IP: '::'.
2016-12-27 15:06:49 1 [Warning] 'proxies_priv' entry '@ root@bd69eb248839' ignored in --skip-name-resolve mode.
2016-12-27 15:06:49 1 [Note] Event Scheduler: Loaded 0 events
2016-12-27 15:06:49 1 [Note] mysqld: ready for connections.
Version: '5.6.35'  socket: '/var/run/mysqld/mysqld.sock'  port: 3306  MySQL Community Server (GPL)

使用DBeaver连接后

查看一下当前~/Docker/test/data/mysql数据库目录下的文件

~/Docker/test/data/mysql  ls
auto.cnf           ib_logfile0        ib_logfile1        ibdata1            mysql              performance_schema

新建一个库docker_test后~/Docker/test/data/mysql数据库目录下的文件

~/Docker/test/data/mysql ls
auto.cnf           docker_test        ib_logfile0        ib_logfile1        ibdata1            mysql              performance_schema

可以发现数据库已经创建好了，也如下图

为了验证数据库数据的持久型，我们先停止当前运行的container并产出它，然后从镜像启动一个新的container，如命令

~/Docker ⮀ docker ps
CONTAINER ID        IMAGE               COMMAND                  CREATED             STATUS              PORTS                    NAMES
970dec0f7de9        phpenv/mysql        "docker-entrypoint.sh"   30 minutes ago      Up 30 minutes       0.0.0.0:3306->3306/tcp   berserk_brown
~/Docker ⮀ docker stop 970dec0f7de9
970dec0f7de9
~/Docker ⮀ docker rm 970dec0f7de9
970dec0f7de9
~/Docker ⮀ docker ps -a
CONTAINER ID        IMAGE                COMMAND                  CREATED             STATUS                      PORTS               NAMES
c82c830770bc        supervisord:latest   "/usr/bin/supervisord"   35 hours ago        Exited (0) 32 minutes ago                       supervisord
~/Docker ⮀ docker run -p 3306:3306 -v ~/Docker/test/data/mysql:/var/lib/mysql -e MYSQL_ROOT_PASSWORD=123456 -it phpenv/mysql
2016-12-27 15:38:04 0 [Note] mysqld (mysqld 5.6.35) starting as process 1 ...
2016-12-27 15:38:04 1 [Warning] Setting lower_case_table_names=2 because file system for /var/lib/mysql/ is case insensitive
2016-12-27 15:38:04 1 [Note] Plugin 'FEDERATED' is disabled.
2016-12-27 15:38:04 1 [Note] InnoDB: Using atomics to ref count buffer pool pages
2016-12-27 15:38:04 1 [Note] InnoDB: The InnoDB memory heap is disabled
2016-12-27 15:38:04 1 [Note] InnoDB: Mutexes and rw_locks use GCC atomic builtins
2016-12-27 15:38:04 1 [Note] InnoDB: Memory barrier is not used
2016-12-27 15:38:04 1 [Note] InnoDB: Compressed tables use zlib 1.2.8
2016-12-27 15:38:04 1 [Note] InnoDB: Using Linux native AIO
2016-12-27 15:38:04 1 [Note] InnoDB: Using CPU crc32 instructions
2016-12-27 15:38:04 1 [Note] InnoDB: Initializing buffer pool, size = 128.0M
2016-12-27 15:38:04 1 [Note] InnoDB: Completed initialization of buffer pool
2016-12-27 15:38:04 1 [Note] InnoDB: Highest supported file format is Barracuda.
2016-12-27 15:38:04 1 [Note] InnoDB: 128 rollback segment(s) are active.
2016-12-27 15:38:04 1 [Note] InnoDB: Waiting for purge to start
2016-12-27 15:38:04 1 [Note] InnoDB: 5.6.35 started; log sequence number 1626037
2016-12-27 15:38:04 1 [Note] Server hostname (bind-address): '*'; port: 3306
2016-12-27 15:38:04 1 [Note] IPv6 is available.
2016-12-27 15:38:04 1 [Note]   - '::' resolves to '::';
2016-12-27 15:38:04 1 [Note] Server socket created on IP: '::'.
2016-12-27 15:38:04 1 [Warning] 'proxies_priv' entry '@ root@bd69eb248839' ignored in --skip-name-resolve mode.
2016-12-27 15:38:04 1 [Note] Event Scheduler: Loaded 0 events
2016-12-27 15:38:04 1 [Note] mysqld: ready for connections.
Version: '5.6.35'  socket: '/var/run/mysqld/mysqld.sock'  port: 3306  MySQL Community Server (GPL)

再次连接数据库验证，发现刚才新建的库docker_test还在，数据库文件持久型保存了。

docker-compose 中mysql配置

待完善

docker-compose 中nginx部署

nginx在构建的时候要替换两个配置文件，Dockfile

FROM nginx:1.10.2

ADD  nginx.conf      /etc/nginx/nginx.conf
ADD  conf.d/*    /etc/nginx/conf.d/

挂载文件在docker-compose里进行定义。

待完善

docker-compose 中php配置

php什么也不做，只通过Dockfile

FROM php:5.6-fpm

来构建

待完善

docker-compose 构建

---

docker-compose文件

nginx:
    build: ./nginx
    ports:
      - "40080:80"
    links:
      - "php"
    volumes:
      - ~/Docker/test/htdocs:/usr/share/nginx/html

php:
    build: ./php
    ports:
      - "49000:9000"
    links:
      - "mysql"
    volumes:
      - ~/Docker/test/htdocs:/var/www/html

mysql:
    build: ./mysql
    ports:
      - "43306:3306"
    volumes:
      - ~/Docker/test/data/mysql:/var/lib/mysql
    environment:
      MYSQL_ROOT_PASSWORD: 123456

记录一下，首先docker-compse是用来集合构建多个镜像的工具，这里我们集合了nginx，php，mysql来搭建一个php的测试环境，在文件中，有一个links参数，是用来连接其他实例，让多个实例之间可以进行通信。

这里有整合文件的下载链接,下载后，将文件放在用户根目录下，命令行执行docker-compose up，结果

~/Docker/test ⮀ docker-compose up
Building mysql
Step 1 : FROM mysql:5.6
---> e1406e1f7c42
Successfully built e1406e1f7c42
WARNING: Image for service mysql was built because it did not already exist. To rebuild this image you must use `docker-compose build` or `docker-compose up --build`.
Building php
Step 1 : FROM php:5.6-fpm
5.6-fpm: Pulling from library/php
75a822cd7888: Already exists
e4d8a4e038be: Pull complete
81d4d961577a: Pull complete
54283fea14a4: Pull complete
a1b82ddb6e57: Pull complete
fe532c795718: Pull complete
f02389f3f13e: Pull complete
5777f6cf03c5: Pull complete
24b45111f193: Pull complete
Digest: sha256:022410892774f45ebd39bdb4df39a4a72e6ae5db96a31ee83e7eb25382cd2491
Status: Downloaded newer image for php:5.6-fpm
---> 55423bcf0cfc
Successfully built 55423bcf0cfc
WARNING: Image for service php was built because it did not already exist. To rebuild this image you must use `docker-compose build` or `docker-compose up --build`.
Building nginx
Step 1 : FROM nginx:1.10.2
---> c2d83d8cde8d
Step 2 : ADD nginx.conf /etc/nginx/nginx.conf
---> e45c0dceafb9
Removing intermediate container ca538d0f2fd1
Step 3 : ADD conf.d/* /etc/nginx/conf.d/
---> bf0d37221331
Removing intermediate container ebaa3b27453a
Successfully built bf0d37221331
WARNING: Image for service nginx was built because it did not already exist. To rebuild this image you must use `docker-compose build` or `docker-compose up --build`.
Creating test_mysql_1
Creating test_php_1
Creating test_nginx_1
Attaching to test_mysql_1, test_php_1, test_nginx_1
mysql_1  | 2016-12-28 07:29:43 0 [Note] mysqld (mysqld 5.6.35) starting as process 1 ...
mysql_1  | 2016-12-28 07:29:43 1 [Warning] Setting lower_case_table_names=2 because file system for /var/lib/mysql/ is case insensitive
mysql_1  | 2016-12-28 07:29:43 1 [Note] Plugin 'FEDERATED' is disabled.
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: Using atomics to ref count buffer pool pages
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: The InnoDB memory heap is disabled
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: Mutexes and rw_locks use GCC atomic builtins
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: Memory barrier is not used
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: Compressed tables use zlib 1.2.8
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: Using Linux native AIO
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: Using CPU crc32 instructions
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: Initializing buffer pool, size = 128.0M
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: Completed initialization of buffer pool
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: Highest supported file format is Barracuda.
php_1    | [28-Dec-2016 07:29:43] NOTICE: fpm is running, pid 1
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: 128 rollback segment(s) are active.
php_1    | [28-Dec-2016 07:29:43] NOTICE: ready to handle connections
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: Waiting for purge to start
mysql_1  | 2016-12-28 07:29:43 1 [Note] InnoDB: 5.6.35 started; log sequence number 1626263
mysql_1  | 2016-12-28 07:29:43 1 [Note] Server hostname (bind-address): '*'; port: 3306
mysql_1  | 2016-12-28 07:29:43 1 [Note] IPv6 is available.
mysql_1  | 2016-12-28 07:29:43 1 [Note]   - '::' resolves to '::';
mysql_1  | 2016-12-28 07:29:43 1 [Note] Server socket created on IP: '::'.
mysql_1  | 2016-12-28 07:29:43 1 [Warning] 'proxies_priv' entry '@ root@bd69eb248839' ignored in --skip-name-resolve mode.
mysql_1  | 2016-12-28 07:29:43 1 [Note] Event Scheduler: Loaded 0 events
mysql_1  | 2016-12-28 07:29:43 1 [Note] mysqld: ready for connections.
mysql_1  | Version: '5.6.35'  socket: '/var/run/mysqld/mysqld.sock'  port: 3306  MySQL Community Server (GPL)

访问一下 http://localhost:40080/index.php ，正常的话，如下图

启动一个真实的代码

下面的代码是今年网络安全周的一个手机在线答题系统，代码很挫，大牛误笑

源码在这里。

将目录直接放在~/Docker/test/htdocs下面，然后在test目录下执行docker-compose up，正常情况下，就会跑起来上面的容器，然后按照代码的README将数据库部署就可以运行了。

参考链接

---

1. Docker 从入门到实践
2. 第一本Docker书
3. 如何进入一个正在运行的Container
4. Docker在PHP项目开发环境中的应用

原文链接：
http://dengnanyi.com/2016/12/24/2016_12/docker-learn-3/
