故障解析丨导入字符串NULL导致主从报错

日期：2023-12-13点击：53收藏

1.背景概述

目前需要搭建一个从库，由于单表数据量较大，时间比较有限，考虑到导入导出的时间，并且GreatSQL支持并行load data的功能，能够加速数据的导入，因此决定使用 select into outfile 和 load data 的方式进行数据的迁移；

在数据导入完成后进行数据同步，从库发生报错 1032 找不到记录，但是登录从库中可以查询到此条记录，这里就很奇怪；

最后通过解析relaylog，根据relaylog中的update记录，以每个字段为查询条件进行查询，发现是由于NULL值列导致的，主库这列的值是 NULL，从库在导入后导成了字符串"NULL"，因此导致回放update操作时匹配不到数据而报错1032.

2.问题复现

本次测试基于 GreatSQL 8.0.32-24

2.1 初始化2个单机实例

略

2.2 主节点创建测试表

greatsql> create database test; greatsql> use test; greatsql> create table t1 (id int, name varchar(30), age int, addr varchar(30), school varchar(30), unique key (id)) engine=innodb; greatsql> insert into t1 values (1,'小红',10,'北京','一中'), (2,'小绿',11,'北京','一中'), (3,'小黄',12,'北京',NULL), (4,'小蓝',13,'北京',NULL), (5,'小黑',14,'北京',NULL);

2.3 查看数据

greatsql> select * from t1; +----+--------+------+--------+--------+ | id | name | age | addr | school | +----+--------+------+--------+--------+ | 1 | 小红 | 10 | 北京 | 一中 | | 2 | 小绿 | 11 | 北京 | 一中 | | 3 | 小黄 | 12 | 北京 | NULL | | 4 | 小蓝 | 13 | 北京 | NULL | | 5 | 小黑 | 14 | 北京 | NULL | +----+--------+------+--------+--------+ 5 rows in set (0.00 sec)

2.4 主节点导出数据

greatsql> select * from test.t1 into outfile '/greatsql/t1.csv' FIELDS TERMINATED BY '|+|' ESCAPED BY '' LINES TERMINATED BY '/*rowsxxx*/';

2.5 查看导出的数据

$ cat t1.csv 1|+|小红|+|10|+|北京|+|一中/*rowsxxx*/2|+|小绿|+|11|+|北京|+|一中/*rowsxxx*/3|+|小黄|+|12|+|北京|+|NULL/*rowsxxx*/4|+|小蓝|+|13|+|北京|+|NULL/*rowsxxx*/5|+|小黑|+|14|+|北京|+|NULL/*rowsxxx

可以看到导出的数据中包含 NULL

2.6 从库创建表并导入数据

greatsql> create database test; use test; create table t1 (id int, name varchar(30), age int, addr varchar(30), school varchar(30), unique key (id)) engine=innodb;

导入数据

greatsql> load data infile '/greatsql/t1.csv' into table test.t1 fields terminated by '|+|' ESCAPED BY '' lines terminated by '/*rowsxxx*/';

2.7 从库查询数据

greatsql> select * from test.t1; +----+--------+------+--------+--------+ | id | name | age | addr | school | +----+--------+------+--------+--------+ | 1 | 小红 | 10 | 北京 | 一中 | | 2 | 小绿 | 11 | 北京 | 一中 | | 3 | 小黄 | 12 | 北京 | NULL | | 4 | 小蓝 | 13 | 北京 | NULL | | 5 | 小黑 | 14 | 北京 | NULL | +----+--------+------+--------+--------+ 5 rows in set (0.00 sec)

2.8 从库建立复制

greatsql> reset master; Query OK, 0 rows affected (0.04 sec) greatsql> set global gtid_purged='b94e6517-68dd-11ee-b43b-00163ecb92e3:1-5755'; Query OK, 0 rows affected (0.00 sec) greatsql> show master status; +---------------+----------+--------------+------------------+---------------------------------------------+ | File | Position | Binlog_Do_DB | Binlog_Ignore_DB | Executed_Gtid_Set | +---------------+----------+--------------+------------------+---------------------------------------------+ | binlog.000001 | 153 | | | b94e6517-68dd-11ee-b43b-00163ecb92e3:1-5755 | +---------------+----------+--------------+------------------+---------------------------------------------+ 1 row in set (0.00 sec) greatsql> change master to master_user='root',master_password='greatdb',master_host='192.168.137.162',master_port=6001,master_auto_position=1; Query OK, 0 rows affected, 7 warnings (0.02 sec) greatsql> start slave; Query OK, 0 rows affected, 1 warning (0.04 sec) greatsql> show slave status\G *************************** 1. row *************************** Slave_IO_State: Waiting for source to send event Master_Host: 192.168.137.162 Master_User: root Master_Port: 6001 Connect_Retry: 60 Master_Log_File: binlog.000002 Read_Master_Log_Pos: 1861574 Relay_Log_File: relaylog.000002 Relay_Log_Pos: 395 Relay_Master_Log_File: binlog.000002 Slave_IO_Running: Yes Slave_SQL_Running: Yes Replicate_Do_DB: ......

2.9 主库更新数据

greatsql> update test.t1 set name='小小黑' where id=5;

2.10 从库查看复制状态

greatsql> show slave status\G *************************** 1. row *************************** Slave_IO_State: Waiting for source to send event Master_Host: 172.17.137.162 Master_User: root Master_Port: 6001 Connect_Retry: 60 Master_Log_File: binlog.000002 Read_Master_Log_Pos: 1863564 Relay_Log_File: relaylog.000002 Relay_Log_Pos: 395 Relay_Master_Log_File: binlog.000002 Slave_IO_Running: Yes Slave_SQL_Running: No Replicate_Do_DB: Replicate_Ignore_DB: Replicate_Do_Table: Replicate_Ignore_Table: Replicate_Wild_Do_Table: Replicate_Wild_Ignore_Table: Last_Errno: 1032 Last_Error: Coordinator stopped because there were error(s) in the worker(s). The most recent failure being: Worker 1 failed executing transaction 'b94e6517-68dd-11ee-b43b-00163ecb92e3:5756' at master log binlog.000002, end_log_pos 1863537. See error log and/or performance_schema.replication_applier_status_by_worker table for more details about this failure or others, if any. Skip_Counter: 0 ...... greatsql> select * from performance_schema.replication_applier_status_by_worker limit 1\G *************************** 1. row *************************** CHANNEL_NAME: WORKER_ID: 1 THREAD_ID: NULL SERVICE_STATE: OFF LAST_ERROR_NUMBER: 1032 LAST_ERROR_MESSAGE: Worker 1 failed executing transaction 'b94e6517-68dd-11ee-b43b-00163ecb92e3:5756' at master log binlog.000002, end_log_pos 1863537; Could not execute Update_rows event on table test.t1; Can't find record in 't1', Error_code: 1032; Can't find record in 't1', Error_code: 1032; handler error HA_ERR_KEY_NOT_FOUND; the event's master log FIRST, end_log_pos 1863537 LAST_ERROR_TIMESTAMP: 2023-10-17 10:02:46.396166 LAST_APPLIED_TRANSACTION: LAST_APPLIED_TRANSACTION_ORIGINAL_COMMIT_TIMESTAMP: 0000-00-00 00:00:00.000000 LAST_APPLIED_TRANSACTION_IMMEDIATE_COMMIT_TIMESTAMP: 0000-00-00 00:00:00.000000 LAST_APPLIED_TRANSACTION_START_APPLY_TIMESTAMP: 0000-00-00 00:00:00.000000 LAST_APPLIED_TRANSACTION_END_APPLY_TIMESTAMP: 0000-00-00 00:00:00.000000 APPLYING_TRANSACTION: b94e6517-68dd-11ee-b43b-00163ecb92e3:5756 APPLYING_TRANSACTION_ORIGINAL_COMMIT_TIMESTAMP: 2023-10-17 10:02:46.392331 APPLYING_TRANSACTION_IMMEDIATE_COMMIT_TIMESTAMP: 2023-10-17 10:02:46.392331 APPLYING_TRANSACTION_START_APPLY_TIMESTAMP: 2023-10-17 10:02:46.393814 LAST_APPLIED_TRANSACTION_RETRIES_COUNT: 0 LAST_APPLIED_TRANSACTION_LAST_TRANSIENT_ERROR_NUMBER: 0 LAST_APPLIED_TRANSACTION_LAST_TRANSIENT_ERROR_MESSAGE: LAST_APPLIED_TRANSACTION_LAST_TRANSIENT_ERROR_TIMESTAMP: 0000-00-00 00:00:00.000000 APPLYING_TRANSACTION_RETRIES_COUNT: 0 APPLYING_TRANSACTION_LAST_TRANSIENT_ERROR_NUMBER: 0 APPLYING_TRANSACTION_LAST_TRANSIENT_ERROR_MESSAGE: APPLYING_TRANSACTION_LAST_TRANSIENT_ERROR_TIMESTAMP: 0000-00-00 00:00:00.000000 1 row in set (0.00 sec)

可以看到从库发生1032报错，找不到记录

2.11 解析从库relay log

#231017 10:02:46 server id 1 end_log_pos 1863456 Table_map: `test`.`t1` mapped to number 180 \# has_generated_invisible_primary_key=0 \# at 673 \#231017 10:02:46 server id 1 end_log_pos 1863537 Update_rows: table id 180 flags: STMT_END_F \### UPDATE `test`.`t1` \### WHERE \### @1=5 /* INT meta=0 nullable=1 is_null=0 */ \### @2='小黑' /* VARSTRING(120) meta=120 nullable=1 is_null=0 */ \### @3=14 /* INT meta=0 nullable=1 is_null=0 */ \### @4='北京' /* VARSTRING(120) meta=120 nullable=1 is_null=0 */ \### @5=NULL /* VARSTRING(120) meta=120 nullable=1 is_null=1 */ \### SET \### @1=5 /* INT meta=0 nullable=1 is_null=0 */ \### @2='小小黑' /* VARSTRING(120) meta=120 nullable=1 is_null=0 */ \### @3=14 /* INT meta=0 nullable=1 is_null=0 */ \### @4='北京' /* VARSTRING(120) meta=120 nullable=1 is_null=0 */ \### @5=NULL /* VARSTRING(120) meta=120 nullable=1 is_null=1 */ \# at 754 \#231017 10:02:46 server id 1 end_log_pos 1863564 Xid = 5940 COMMIT/*!*/; SET @@SESSION.GTID_NEXT= 'AUTOMATIC' /* added by greatsqlbinlog */ /*!*/; DELIMITER ; \# End of log file

可以看到update更新前的数据与从库的数据一致，那么为什么还会报错找不到记录呢？

2.12 根据relay log中的内容去从库查询数据

greatsql> select * from test.t1 where id=5; +------+--------+------+--------+--------+ | id | name | age | addr | school | +------+--------+------+--------+--------+ | 5 | 小黑 | 14 | 北京 | NULL | +------+--------+------+--------+--------+ 1 row in set (0.01 sec) greatsql> select * from test.t1 where name='小黑'; +------+--------+------+--------+--------+ | id | name | age | addr | school | +------+--------+------+--------+--------+ | 5 | 小黑 | 14 | 北京 | NULL | +------+--------+------+--------+--------+ 1 row in set (0.01 sec) greatsql> select * from test.t1 where age=14; +------+--------+------+--------+--------+ | id | name | age | addr | school | +------+--------+------+--------+--------+ | 5 | 小黑 | 14 | 北京 | NULL | +------+--------+------+--------+--------+ 1 row in set (0.00 sec) greatsql> select * from test.t1 where addr='北京'; +------+--------+------+--------+--------+ | id | name | age | addr | school | +------+--------+------+--------+--------+ | 1 | 小红 | 10 | 北京 | 一中 | | 2 | 小绿 | 11 | 北京 | 一中 | | 3 | 小黄 | 12 | 北京 | NULL | | 4 | 小蓝 | 13 | 北京 | NULL | | 5 | 小黑 | 14 | 北京 | NULL | +------+--------+------+--------+--------+ 5 rows in set (0.00 sec) greatsql> select * from test.t1 where school is null; Empty set (0.01 sec) greatsql> select * from test.t1 where school='null'; +------+--------+------+--------+--------+ | id | name | age | addr | school | +------+--------+------+--------+--------+ | 3 | 小黄 | 12 | 北京 | NULL | | 4 | 小蓝 | 13 | 北京 | NULL | | 5 | 小黑 | 14 | 北京 | NULL | +------+--------+------+--------+--------+ 3 rows in set (0.00 sec)

可以看到，根据null值作为查询条件时，匹配不到数据；根据字符串"null" 进行匹配是可以匹配到数据

2.13 去主库进行查询

greatsql> select * from test.t1 where school is null; +------+-----------+------+--------+--------+ | id | name | age | addr | school | +------+-----------+------+--------+--------+ | 3 | 小黄 | 12 | 北京 | NULL | | 4 | 小蓝 | 13 | 北京 | NULL | | 5 | 小小黑 | 14 | 北京 | NULL | +------+-----------+------+--------+--------+ 3 rows in set (0.00 sec) greatsql> select * from test.t1 where school='null'; Empty set (0.00 sec)

在主库查询的结果与从库相反

可以得出结论，由于从库导入的数据将NULL值列的数据导入成了字符串 NULL，因此导致主从数据出现了不一致。

2.14 修复从库

greatsql> stop slave; Query OK, 0 rows affected, 1 warning (0.00 sec) greatsql> update test.t1 set school=NULL where school='null'; Query OK, 3 rows affected (0.01 sec) Rows matched: 3 Changed: 3 Warnings: 0 greatsql> start slave; Query OK, 0 rows affected, 1 warning (0.04 sec) greatsql> show slave status\G *************************** 1. row *************************** Slave_IO_State: Waiting for source to send event Master_Host: 172.17.137.162 Master_User: root Master_Port: 6001 Connect_Retry: 60 Master_Log_File: binlog.000002 Read_Master_Log_Pos: 1863564 Relay_Log_File: relaylog.000003 Relay_Log_Pos: 435 Relay_Master_Log_File: binlog.000002 Slave_IO_Running: Yes Slave_SQL_Running: Yes Replicate_Do_DB: ......

可以看到主从状态已经恢复正常
