以OneFlow为例探索MLIR的实际开发流程

1

前言

本文提到的Op和Operation是一回事，没有严格区分。

2

OneFlow是如何和MLIR结合的？


 git clone git@github.com:Oneflow-Inc/oneflow.git
cd oneflow && mkdir build && cd build
cmake-C ../cmake/caches/cn/fast/mlir-cuda-75.cmake -DBUILD_TESTING=ON .. && ninja



 os.environ["ONEFLOW_MLIR_ENABLE_ROUND_TRIP"] = '1'
os.environ["ONEFLOW_MLIR_ENABLE_CODEGEN_FUSERS"] = '1'

@flow.unittest.skip_unless_1n1d()
class TestFuseBiasAddGeLUCPUMLIR(oneflow.unittest.TestCase):
    def test_fused_bias_add_gelu_graph(test_case):
        data = np.random.randn(1, 2, 3)
        bias_data = np.random.randn(2)
        x = flow.tensor(data, dtype=flow.float32)
        bias = flow.tensor(bias_data, dtype=flow.float32)
        y_eager = flow.gelu(flow._C.bias_add(x, bias, axis=1))

        class FuseBiasAddGeLUGraph(flow.nn.Graph):
            def __init__(self):
                super().__init__()

            def build(self, x):
                return flow.gelu(flow._C.bias_add(x, bias, axis=1))

        bias_add_gelu = FuseBiasAddGeLUGraph()
        y_lazy = bias_add_gelu(x)
        test_case.assertTrue(np.array_equal(y_eager.numpy(), y_lazy.numpy()))



 REGISTER_JOB_PASS("IRRoundTripBeforeAD", IRRoundTrip<kBeforeAD>);
REGISTER_JOB_PASS("IRRoundTrip", IRRoundTrip<kAfterAD>);



 def OneFlow_ReshapeOp : OneFlow_BaseOp<"reshape", [NoSideEffect, DeclareOpInterfaceMethods<UserOpCompatibleInterface>]> {
  let input = (ins
    AnyType:$in
  );
  let output = (outs
    AnyType:$out
  );
  let attrs = (ins
    AnyI64ElementsAttr:$shape
  );
}



 REGISTER_USER_OP("reshape")
    .Input("in")
    .Output("out")
    .Attr<Shape>("shape")
    ...



3

OneFlow IR如何执行？


 void AddLowerToLinalgMemRefPasses(PassManager& pm) {
  pm.addPass(createLowerOneFlowToTosaPass());            // lower-oneflow-to-tosa
  pm.addPass(createCSEPass());                           // cse
  pm.addNestedPass<FuncOp>(tosa::createTosaToLinalg());  // tosa-to-linalg-on-tensors
  auto p = createLinalgElementwiseOpFusionPass();
  assert(p->initializeOptions("allow-folding-unit-dim-reshapes=true").succeeded());
  pm.addNestedPass<FuncOp>(std::move(p));                     // linalg-fuse-elementwise-ops
  pm.addNestedPass<FuncOp>(createLinalgBufferizePass());      // linalg-bufferize
  pm.addNestedPass<FuncOp>(createTensorBufferizePass());      // tensor-bufferize
  pm.addPass(createTensorConstantBufferizePass());            // tensor-constant-bufferize
  pm.addPass(createFuncBufferizePass());                      // func-bufferize
  pm.addPass(createBufferResultsToOutParamsPass());           // buffer-results-to-out-params
  pm.addPass(createCanonicalizerPass());                      // canonicalize
  pm.addNestedPass<FuncOp>(createFinalizingBufferizePass());  // finalizing-bufferize
}

LogicalResult LowerModuleToLLVM(mlir::MLIRContext* context, ModuleOp module) {
  mlir::PassManager pm(context);
  AddLowerToLinalgMemRefPasses(pm);
  pm.addNestedPass<FuncOp>(createConvertLinalgToLoopsPass());  // convert-linalg-to-loops
  pm.addNestedPass<FuncOp>(createLowerToCFGPass());            // convert-scf-to-std
  pm.addPass(createConvertLinalgToLLVMPass());                 // convert-linalg-to-llvm
  pm.addPass(createMemRefToLLVMPass());                        // convert-memref-to-llvm
  pm.addPass(createLowerToLLVMPass());                         // convert-std-to-llvm
  pm.addPass(createReconcileUnrealizedCastsPass());
  return pm.run(module);
}



 class OutlineJitFunctionPass : public OutlineJitFunctionPassBase<OutlineJitFunctionPass> {
  void runOnOperation() override {
    Operation* op = getOperation();
    RewritePatternSet patterns(op->getContext());
    oneflow::populateFuserPasses(patterns);
    (void)applyPatternsAndFoldGreedily(op, std::move(patterns));
  }
};

std::unique_ptr<Pass> createOutlineJitFunctionPass() {
  return std::make_unique<OutlineJitFunctionPass>();
}

LogicalResult ApplyRoundTripPatterns(RoundTripOneFlowJobWrapperInterface& job_wrapper,
                                     MLIRContext* context, OwningModuleRef& module) {
  mlir::PassManager pm(context);
  pm.addNestedPass<mlir::FuncOp>(::mlir::createCanonicalizerPass());
  if (job_wrapper.IsLastIRPass() && std::getenv("ONEFLOW_MLIR_ENABLE_CODEGEN_FUSERS") != nullptr) {
    pm.addPass(oneflow::createOutlineJitFunctionPass());
  }
  ...
}


• 第一个问题是如何做Op融合。上面的JIT执行流程只考虑了不断Lowering，那么假如在OneFlow Dialect中有一些Operation是可以融合的，这个时候应该怎么做呢？很简单，我们沿用一下MLIR的DRR规则，还是用TableGen语法在oneflow/ir/include/OneFlow/OneFlowPatterns.td 中写一系列的Fuse Pattern即可，比如bias_add+gelu 这两个Op可以融合成OneFlow中的fused_bias_add_gelu Op，那么就可以写如下的规则。


 def IsGPU: Constraint<CPred<"$0.getValue().equals(\"gpu\")">, "is GPU device">;
def FusedBiasAddGeluPattern : Pat<
  (
    OneFlow_GeluOp : $gelu_op
    (
      OneFlow_BiasAddOp
        $a,
        $b,
        $bias_add_op_name,
        $bias_add_device_tag,
        $bias_add_device_name,
        $bias_add_scope_symbol_id,
        $bias_add_hierarchy,
        $axis
    ),
    $gelu_op_name,
    $gelu_device_tag,
    $gelu_device_name,
    $gelu_scope_symbol_id,
    $gelu_hierarchy
  ),
  (OneFlow_FusedBiasAddGeluOp $a, $b,
    $gelu_op_name,
    $gelu_device_tag,
    $gelu_device_name,
    $gelu_scope_symbol_id,
    $gelu_hierarchy,
    $axis
  ),
  [
    (IsGPU $bias_add_device_tag),
    (IsGPU $gelu_device_tag)
  ]
>;


• 第二个问题是如何让OneFlow的一些Operation享受MLIR基础设施中的更多优化？在多级Dialect 逐层下降时可以看到OneFlow的MLIR表达式的每个子函数都会被Lower。第一次会将其Lower到Tosa Dialect，这个时候如果这个子函数中的某个Operation没有定义转换到Tosa Dialect的方法，那么就不能Lower到Tosa Dialect。自然也就不能进一步下降为Linalg Dialect，享受不到一些循环变化带来的优化（我感觉可以类比TVM的scheduler优化）。




  为了解决这种情况我们需要额外再定义一个Pass来将当前需要转换为Tosa的Op或者模式提取成一个函数，里面的oneflow op都能够lower到tosa，然后生成一个 oneflow mlir jit op 来 call 这个函数：


 def IsNotNestedInJit: Constraint<CPred<"(!$0.getDefiningOp()->getParentOfType<::mlir::FuncOp>()->hasAttr(\"llvm.emit_c_interface\"))">, "">;
def OutlineMulCast : NativeCodeCall<"::mlir::oneflow::OutlineMulCast($_builder, $0, $1)">;
// TODO: remove attr binding if possible
def MulCastPattern : Pat<
  (
    OneFlow_ScalarMulByTensorOp : $mul_op
    (
      OneFlow_CastOp : $cast_op
        $cast_x,
        $cast_op_name,
        $cast_device_tag,
        $cast_device_name,
        $cast_scope_symbol_id,
        $cast_hierarchy,
        $cast_dtype
    ),
    $scalar,
    $mul_op_name,
    $mul_device_tag,
    $mul_device_name,
    $mul_scope_symbol_id,
    $mul_hierarchy
  ),
  (OutlineMulCast $mul_op, $cast_op),
  [
    (IsNotNestedInJit $mul_op)
  ]
>;

::llvm::SmallVector<::mlir::Value, 4> OutlineMulCast(::mlir::PatternRewriter& rewriter,
                                                     mlir::OpResult mul_res,
                                                     mlir::OpResult cast_res) {
  if (auto mul_op = llvm::dyn_cast<ScalarMulByTensorOp>(mul_res.getDefiningOp())) {
    if (auto cast_op = llvm::dyn_cast<CastOp>(cast_res.getDefiningOp())) {
      // TODO: extract a function to generate op name for jit op from ops being fused
      SmallString<64> op_name_storage;
      auto op_name =
          (cast_op.op_name() + "__FUSE__" + mul_op.op_name()).toStringRef(op_name_storage);
      SmallVector<::mlir::Value, 2> operands;
      operands.push_back(cast_op.in());
      operands.push_back(mul_op.scalar());
      SmallVector<::mlir::Value, 1> results;
      results.push_back(mul_op.y());
      NamedAttrList attributes =
          GetJitOpAttributes(rewriter, op_name, operands.size(), results.size(), mul_op);
      SmallVector<Operation*, 4> ops = {cast_op, mul_op};
      auto function =
          GetOrInsertFuncOp(rewriter, mul_op->getLoc(), op_name, operands, results, ops);
      auto created = rewriter.create<MlirJitOp>(mul_op.getLoc(), function, attributes, operands);
      assert(DumpAssembly(rewriter, created).succeeded());
      cast_op->dropAllUses();
      cast_op.erase();
      return created->getResults();
    }
  }
  return {};
}

void populateFuserPasses(::mlir::RewritePatternSet& patterns) {
  patterns.add<MulCastPattern>(patterns.getContext());
}
